WWC 24 AWG 6 Pair Mist Grey Data Cable Overall Screened Polypropylene/PVC
WWC 24 AWG 6 Pair Mist Grey Data Cable Overall Screened Polypropylene/PVC
In stock
SKU
WWC4006
Data Cable, 24 AWG, Class 2 Tinned Annealed Copper, 0.3 kV, 6 Pair, 7/0.2 mm Strands, Overall Screened Screen, 7.6 mm Overall Diameter, 48 mm Bend Radius, 0.3 mm Insulation Thickness, DC: 10 Ohm/100m Conductor Resistance, 100% Screen Coverage, Aluminium Foil/Polyester Tape w/Tinned Annealed Copper Drain Wire Screen, Polypropylene Insulation, 4V-75 PVC Sheath, Mist Grey Sheath, -15 to 105 deg C, AS/NZS 1125 AS/NZS 3808 AS/NZS 1660.5.6 AS/NZS 1660.5.1 UL 2493
| Brand | WWC |
|---|---|
| Standard Pack Size | 1 |
| UNSPSC Class | 26121600 |
| UOM | MTR |
| Vendor Product | 4006 |
| Conductor Resistance | DC: 10 Ohm/100m |
| Bend Radius | 48 mm |
| Conductor Size | 24 AWG |
| Conductor Type | Class 2 Tinned Annealed Copper |
| Insulation Material | Polypropylene |
| Insulation Thickness | 0.3 mm |
| Number of Pairs | 6 Pair |
| Overall Diameter | 7.6 mm |
| Product Type | Data Cable |
| Screen Format | Overall Screened |
| Screen Coverage | 100% |
| Screen Material | Aluminium Foil/Polyester Tape w/Tinned Annealed Copper Drain Wire |
| Sheath Colour | Mist Grey |
| Sheath Material | 4V-75 PVC |
| Standards | AS/NZS 1125 AS/NZS 3808 AS/NZS 1660.5.6 AS/NZS 1660.5.1 UL 2493 |
| Stranding | 7/0.2 mm |
| Temperature | -15 to 105 deg C |
| Voltage | 0.3 kV |
Description
Data Cable, 24 AWG, Class 2 Tinned Annealed Copper, 0.3 kV, 6 Pair, 7/0.2 mm Strands, Overall Screened Screen, 7.6 mm Overall Diameter, 48 mm Bend Radius, 0.3 mm Insulation Thickness, DC: 10 Ohm/100m Conductor Resistance, 100% Screen Coverage, Aluminium Foil/Polyester Tape w/Tinned Annealed Copper Drain Wire Screen, Polypropylene Insulation, 4V-75 PVC Sheath, Mist Grey Sheath, -15 to 105 deg C, AS/NZS 1125 AS/NZS 3808 AS/NZS 1660.5.6 AS/NZS 1660.5.1 UL 2493
