WWC 16mm Orange Circular Cable Unarmoured X-90 XLPE/5V-90 PVC 1mtr
WWC 16mm Orange Circular Cable Unarmoured X-90 XLPE/5V-90 PVC 1mtr
In stock
SKU
WWC1316UA
Circular Cable, Unarmoured, 16mm, Class 2 Annealed Copper, 0.6-1 kV, 2 Core + Earth, 5.2mm Core Diameter, 4.8mm Nominal Diameter, 17.2mm Overall Diameter, 6mm Earth Conductor, 1 mtr Length, 0.7mm Insulation Thickness, DC: 1.15 Ohm/km Conductor Resistance, Red/Black/Green/Yellow Core, X-90 XLPE Insulation, 5V-90 PVC Sheath, Orange Sheath, -40 to 90 deg C, AS/NZS 1125 AS/NZS 3808 AS/NZS 5000.1 AS/NZS 1660.5.6
| Brand | WWC |
|---|---|
| Range Name | Vipercon |
| Standard Pack Size | 1 |
| UNSPSC Class | 26121600 |
| UOM | MTR |
| Vendor Product | 1316UA |
| Conductor Resistance | DC: 1.15 Ohm/km |
| Conductor Size | 16 mm |
| Conductor Type | Class 2 Annealed Copper |
| Core Colours | Black/Red/Green/Yellow |
| Core Diameter | 5.2 mm |
| Insulation Thickness | 0.7 mm |
| Insulation Material | X-90 XLPE |
| Earth Conductor Size | 6 mm |
| Length | 1 mtr |
| Nominal Diameter | 4.8 mm |
| Number of Cores | 2 Core + Earth |
| Overall Diameter | 17.2 mm |
| Product Type | Circular Cable Unarmoured |
| Sheath Colour | Orange |
| Sheath Material | 5V-90 PVC |
| Standards | AS/NZS 1125 AS/NZS 3808 AS/NZS 5000.1 AS/NZS 1660.5.6 |
| Temperature | -40 to 90 deg C |
| Voltage | 0.6-1 kV |
Description
Circular Cable, Unarmoured, 16mm, Class 2 Annealed Copper, 0.6-1 kV, 2 Core + Earth, 5.2mm Core Diameter, 4.8mm Nominal Diameter, 17.2mm Overall Diameter, 6mm Earth Conductor, 1 mtr Length, 0.7mm Insulation Thickness, DC: 1.15 Ohm/km Conductor Resistance, Red/Black/Green/Yellow Core, X-90 XLPE Insulation, 5V-90 PVC Sheath, Orange Sheath, -40 to 90 deg C, AS/NZS 1125 AS/NZS 3808 AS/NZS 5000.1 AS/NZS 1660.5.6
