Wideband Outlet Mechanism Cat6+ UTP RJ45 Black
Wideband Outlet Mechanism Cat6+ UTP RJ45 Black
In stock
SKU
WIDMJU6+BKSI
Outlet Mechanism Cat6+ UTP, 1.5 Amp, Stranded: 22-26 AWG, RJ45 Connector, Cat6+ UTP Cable, 0.1 Ohm Contact Resistance, 500 MOhm Insulation Resistance, 20 lb Plug Retention Force, Flammability: UL94V-0, IDC Termination, High-Impact Flame Retardant Plastic Housing, Black,-40 to 68 deg C
| Brand | Wideband |
|---|---|
| Standard Pack Size | 1 |
| UNSPSC Class | 39121400 |
| UOM | EA |
| Vendor Product | MJU6+BKSI |
| Cable Type | Cat6+ UTP |
| Colour | Black |
| Conductor Size | Stranded: 22-26 AWG |
| Connector | RJ45 |
| Contact Resistance | 0.1 Ohm |
| Current | 1.5 Amp |
| Flammability | UL94V-0 |
| Housing Material | High Impact Flame Retardant Plastic |
| Insulation Resistance | 500 MOhm |
| Temperature | -40 to 68 deg C |
| Termination Type | IDC |
Description
Outlet Mechanism Cat6+ UTP, 1.5 Amp, Stranded: 22-26 AWG, RJ45 Connector, Cat6+ UTP Cable, 0.1 Ohm Contact Resistance, 500 MOhm Insulation Resistance, 20 lb Plug Retention Force, Flammability: UL94V-0, IDC Termination, High-Impact Flame Retardant Plastic Housing, Black,-40 to 68 deg C
