Tycab Flexible Wire Single Insulated 1 Core 0.75mm 250/440V Tinned Annealed Copper V90HT PVC Blue
Tycab Flexible Wire Single Insulated 1 Core 0.75mm 250/440V Tinned Annealed Copper V90HT PVC Blue
In stock
SKU
TYCFVT12402-LB-100
Flexible Wire, Single Insulated, 1 Core, 0.75 mm, Tinned Annealed Copper, 250/440 Volt, 12 Amp, 24/0.2 mm Strands, 2.4 mm Overall Diameter, 0.6 mm Insulation Thickness, Conductor Resistance: 26.7 Ohm/km, RoHS Compliant V-90HT PVC Insulation, Unsheathed, Blue Insulation, 75 deg C
| Brand | Tycab |
|---|---|
| Standard Pack Size | 100 |
| UNSPSC Class | 26121600 |
| UOM | MTR |
| Vendor Product | FVT12402-LB-100 |
| Conductor Resistance | 26.7 Ohm/km |
| Conductor Size | 0.75 mm |
| Conductor Type | Tinned Annealed Copper |
| Current | 12 Amp |
| Insulation Colour | Blue |
| Insulation Material | RoHS Compliant V-90HT PVC |
| Insulation Thickness | 0.6 mm |
| Overall Diameter | 2.4 mm |
| Number of Cores | 1 Core |
| Product Type | Flexible Cable |
| Sheath Material | Unsheathed |
| Stranding | 24/0.2 mm |
| Temperature | 75 deg C |
| Voltage | 250-440 Volt |
Description
Flexible Wire, Single Insulated, 1 Core, 0.75 mm, Tinned Annealed Copper, 250/440 Volt, 12 Amp, 24/0.2 mm Strands, 2.4 mm Overall Diameter, 0.6 mm Insulation Thickness, Conductor Resistance: 26.7 Ohm/km, RoHS Compliant V-90HT PVC Insulation, Unsheathed, Blue Insulation, 75 deg C
