Tycab 1.5mm Grey Flexible Wire V90HT PVC
Tycab 1.5mm Grey Flexible Wire V90HT PVC
In stock
SKU
TYCFVK130025-SY-100
Flexible Wire, 1.5 mm, Tinned Annealed Copper, 0.6-1 kV, 21 Amp, 1 Core, 30/0.25 mm Strands, 3.15 mm Overall Diameter, 0.8 mm Insulation Thickness, 13.7 Ohm/km Conductor Resistance, RoHS Compliant V-90HT PVC Insulation, Grey Insulation, Unsheathed, 75 deg C, AS/NZS 3008.1.1:2009
| Brand | Tycab |
|---|---|
| Standard Pack Size | 100 |
| UNSPSC Class | 26121500 |
| UOM | MTR |
| Vendor Product | FVK130025-SY-100 |
| Conductor Resistance | 13.7 Ohm/km |
| Conductor Size | 1.5 mm |
| Conductor Type | Tinned Annealed Copper |
| Current | 21 Amp |
| Insulation Colour | Grey |
| Insulation Material | RoHS Compliant V-90HT PVC |
| Insulation Thickness | 0.8 mm |
| Overall Diameter | 3.15 mm |
| Number of Cores | 1 Core |
| Sheath Material | Unsheathed |
| Standards | AS/NZS 3008.1.1:2009 |
| Stranding | 30/0.25 mm |
| Temperature | 75 deg C |
| Voltage | 0.6-1 kV |
Description
Flexible Wire, 1.5 mm, Tinned Annealed Copper, 0.6-1 kV, 21 Amp, 1 Core, 30/0.25 mm Strands, 3.15 mm Overall Diameter, 0.8 mm Insulation Thickness, 13.7 Ohm/km Conductor Resistance, RoHS Compliant V-90HT PVC Insulation, Grey Insulation, Unsheathed, 75 deg C, AS/NZS 3008.1.1:2009
