Terasaki Miniature Circuit Breaker D Curve 63Amp 10 kA 3Pole 3Module 54mm DIN 35mm Rail Mount
Terasaki Miniature Circuit Breaker D Curve 63Amp 10 kA 3Pole 3Module 54mm DIN 35mm Rail Mount
In stock
SKU
TERDTCB10363D
Miniature Circuit Breaker D Curve, 415 Volt, 63 Amp, 50/60 Hz, 10 kA Interrupt Capacity, 3 Module 54 mm, 3 Pole, 4.5 Nm Top/Bottom Tightening Torque, Pin/Fork Terminal, 0.75-25 sq-mm Flexible/1-35 sq-mm Rigid, IP20/40, DIN Rail Mounting, 25 to 55 deg C, 86 mm Height, 54 mm Width, 76 mm Depth
| Features |
|
|---|---|
| Brand | Terasaki |
| Range Name | Din-T10 |
| Standard Pack Size | 1 |
| UNSPSC Class | 39121600 |
| UOM | EA |
| Vendor Product | DTCB10363D-NLA |
| Cable Size | 0.75-25 sq-mm Flexible / 1-35 sq-mm Rigid |
| Current | 63 Amp |
| Depth | 76 mm |
| Frequency | 50/60 Hz |
| Height | 86 mm |
| Interrupt Capacity | 10 kA |
| IP Rating | IP20/40 |
| Modules | 3 Module 54 mm |
| Mounting Method | DIN Rail |
| Number Of Poles | 3 Pole |
| Product Type | Mini Circuit Breakers |
| Temperature | 25 to 55 deg C |
| Terminal Type | Pin/Fork |
| Tightening Torque | 4.5 Nm |
| Voltage | 415 Volt |
| Width | 54 mm |
Description
Miniature Circuit Breaker D Curve, 415 Volt, 63 Amp, 50/60 Hz, 10 kA Interrupt Capacity, 3 Module 54 mm, 3 Pole, 4.5 Nm Top/Bottom Tightening Torque, Pin/Fork Terminal, 0.75-25 sq-mm Flexible/1-35 sq-mm Rigid, IP20/40, DIN Rail Mounting, 25 to 55 deg C, 86 mm Height, 54 mm Width, 76 mm Depth
