NHP Combination RCD Circuit Breaker RCBO 1P+ N 32 Amp 240V AC 10 kA 2Module 36mm DIN 35 Rail
NHP Combination RCD Circuit Breaker RCBO 1P+ N 32 Amp 240V AC 10 kA 2Module 36mm DIN 35 Rail
In stock
SKU
TERDSRCB3230A
Residual Current Device, 240 Volt, 32 Amp, 50/60 Hz, 10 kA Interrupt Capacity, 30 mA Trip Sensitivity, C Curve, 1 + N Pole, 2 Module 36 mm, 1-16 sq-mm/1-25 sq-mm Flexible/1-25 sq-mm/1-35 sq-mm Rigid Terminal, Pin/Fork Connection, IP20/40, DIN Rail Mounting, 5 to 55 deg C, 86 mm Height, 36 mm Width, 68 mm Depth
| Features |
|
|---|---|
| Brand | NHP |
| Range Name | Din-Safe |
| Standard Pack Size | 1 |
| UNSPSC Class | 39121600 |
| UOM | EA |
| Vendor Product | DSRCB3230A-NLA |
| Current | 32 Amp |
| Connection Type | Pin/Fork |
| Depth | 68 mm |
| Height | 86 mm |
| Frequency | 50/60 Hz |
| IP Rating | IP20/40 |
| Interrupt Capacity | 10 kA |
| Modules | 2 Module 36 mm |
| Mounting Method | DIN Rail |
| Number Of Poles | 1 Pole |
| Terminal Connection | 1-16 sq-mm / 1-25 sq-mm Flexible / 1-25 sq-mm / 1-35 sq-mm Rigid |
| Temperature | 5 to 55 deg C |
| Trip Characteristic | C Curve |
| Voltage | 240 Volt |
| Trip Sensitivity | 30 mA |
| Width | 36 mm |
Description
Residual Current Device, 240 Volt, 32 Amp, 50/60 Hz, 10 kA Interrupt Capacity, 30 mA Trip Sensitivity, C Curve, 1 + N Pole, 2 Module 36 mm, 1-16 sq-mm/1-25 sq-mm Flexible/1-25 sq-mm/1-35 sq-mm Rigid Terminal, Pin/Fork Connection, IP20/40, DIN Rail Mounting, 5 to 55 deg C, 86 mm Height, 36 mm Width, 68 mm Depth
