Teco Electric Motor Squirrel Cage Induction 4P 0.37kW 1Ph 240V D71 Frame Flange Mount
Teco Electric Motor Squirrel Cage Induction 4P 0.37kW 1Ph 240V D71 Frame Flange Mount
In stock
SKU
TEO134/0.37MV4
Electric Motor Squirrel Cage Induction, 240 Volt AC, 2.6 Amp, 0.37 kW, 50 Hz, 1 Phase, 1400 rpm, 4 Pole, IP55, Frame: D71, Shaft Size: 14 mm, Duty Cycle: S1, Ball Bearing, Torque: 35 N/m, Flange Mount, Insulation Class: Class F, <80 deg C, Aluminium, Teal, 255 mm Length x 205 mm Height
| Features |
|
|---|---|
| Brand | Teco |
| Range Name | Monarch Single Phase |
| Standard Pack Size | 1 |
| UNSPSC Class | 26101100 |
| UOM | EA |
| Vendor Product | 134/0.37MV4 |
| Colour | Teal |
| Current | 2.6 Amp |
| Bearing Type | Ball |
| Frame | Size D71 |
| Height | 205 mm |
| Frequency | 50 Hz |
| Insulation Class | Class F |
| IP Rating | IP55 |
| Horsepower | 0.37 kW |
| Length | 255 mm |
| Mounting Method | Flange |
| Material | Aluminium |
| Number Of Poles | 4 Pole |
| Product Type | Motors SCIM |
| Phase | 1 Phase |
| Shaft Size | 14 mm |
| Speed | 1400 rpm |
| Temperature | <80 deg C |
| Voltage | 240 Volt AC |
| Torque Rating | 35 N/m |
Description
Electric Motor Squirrel Cage Induction, 240 Volt AC, 2.6 Amp, 0.37 kW, 50 Hz, 1 Phase, 1400 rpm, 4 Pole, IP55, Frame: D71, Shaft Size: 14 mm, Duty Cycle: S1, Ball Bearing, Torque: 35 N/m, Flange Mount, Insulation Class: Class F, <80 deg C, Aluminium, Teal, 255 mm Length x 205 mm Height
