Teco Electric Motor Squirrel Cage Induction 4P 0.75kW 1Ph 240V D80 Frame Foot Mount
Teco Electric Motor Squirrel Cage Induction 4P 0.75kW 1Ph 240V D80 Frame Foot Mount
In stock
SKU
TEO132/0.75YE4
Electric Motor Squirrel Cage Induction, 240 Volt AC, 5 Amp, 0.75 kW, 50 Hz, 1 Phase, 1400 rpm, 4 Pole, IP55, Frame: D80, Shaft Size: 19 mm, Duty Cycle: S1, Ball Bearing, Torque: 32 N/m, Foot Mount, Insulation Class: Class F, <80 deg C, Aluminium, Teal, 295 mm Length x 235 mm Height
| Features |
|
|---|---|
| Brand | Teco |
| Range Name | Monarch Single Phase |
| Standard Pack Size | 1 |
| UNSPSC Class | 26101100 |
| UOM | EA |
| Vendor Product | 132/0.75YE4 |
| Colour | Teal |
| Current | 5 Amp |
| Bearing Type | Ball |
| Frame | Size D80 |
| Height | 235 mm |
| Frequency | 50 Hz |
| Insulation Class | Class F |
| IP Rating | IP55 |
| Horsepower | 0.75 kW |
| Length | 295 mm |
| Mounting Method | Foot |
| Material | Aluminium |
| Number Of Poles | 4 Pole |
| Product Type | Motors SCIM |
| Phase | 1 Phase |
| Shaft Size | 19 mm |
| Speed | 1400 rpm |
| Temperature | <80 deg C |
| Voltage | 240 Volt AC |
| Torque Rating | 32 N/m |
Description
Electric Motor Squirrel Cage Induction, 240 Volt AC, 5 Amp, 0.75 kW, 50 Hz, 1 Phase, 1400 rpm, 4 Pole, IP55, Frame: D80, Shaft Size: 19 mm, Duty Cycle: S1, Ball Bearing, Torque: 32 N/m, Foot Mount, Insulation Class: Class F, <80 deg C, Aluminium, Teal, 295 mm Length x 235 mm Height
