Diginet Light Dimmer Mechanism Rotary Universal 2 Wire 240V 400W White

Diginet Light Dimmer Mechanism Rotary Universal 2 Wire 240V 400W White

In stock
SKU
SYLMEDM
The Diginet MEDM Adaptive Phase Dimmer is designed in Australia to provide optimised dimming of LED based lamps and drivers, this high quality, two-wire phase control wall plate dimmer has a minimum load rating of 2W, allowing it to adapt to a wide range of available LED drivers. Although optimised for LED lighting loads, this dimmer also provides excellent compatibility with other common lamps types such as incandescent lamps, 12V halogen (dichroic) lamps /transformers and CFL's.
More Information
Features
  • Maximum 400 W load
  • Incorporates filtering to reduce load brightness variation
  • Stable operation with most non-dimmable lamps (to a limited dimming level, lamp dependent)
  • LED Illuminated rotary dial for smooth and easy min/max adjustment
  • No neutral wire connection required for wall-plate retrofit installation (2-wire dimmer)
  • Incorporates a thermal fuse to protect itself against overheating
  • Incorporates filtering to reduce load brightness variation under conditions of line voltage ripple signal injection
  • Analogue rotary dial with hardstop at maximum and minimum
  • Green LED indicator
  • Indicator stays ON when lights are switched off
Brand Diginet
Standard Pack Size 1
UNSPSC Class 39122200
UOM EA
Vendor Product MEDM
Colour White
Control Type Rotary
Depth 41 mm
For Use With Wall Switch Plate Apertures
Height 41 mm
IP Rating IP20
Frequency 50 Hz
Length 24 mm
Mounting Method Wall
Number of Wires 2 Wire
Product Type Dimmer Mechanisms
Temperature 0 to 50 deg C
Voltage 240 Volt
Wattage 400 Watt
Width 23.7 mm

Description

The Diginet MEDM Adaptive Phase Dimmer is designed in Australia to provide optimised dimming of LED based lamps and drivers, this high quality, two-wire phase control wall plate dimmer has a minimum load rating of 2W, allowing it to adapt to a wide range of available LED drivers. Although optimised for LED lighting loads, this dimmer also provides excellent compatibility with other common lamps types such as incandescent lamps, 12V halogen (dichroic) lamps /transformers and CFL's.
