Surefit Hazardous Area Cable Gland Unarmoured 9-11.9mm M20 x 1.5 IP66/68
Surefit Hazardous Area Cable Gland Unarmoured 9-11.9mm M20 x 1.5 IP66/68
In stock
SKU
SURGWPMEX1A
Nickel plated brass cable glands for use with circular unarmoured cables to secure the cable and to provide an Explosion Protected, Weatherproof and Dust Excluding Ignition Proof entry into panels or enclosures that meet these requirements. The cable glands in this range are suitable for use in machine and equipment applications where an Explosion Protected, unarmoured, Weatherproof gland type termination is required.
| Features |
|
|---|---|
| Brand | Surefit |
| Range Name | Type GWPMEX |
| Standard Pack Size | 10 |
| UNSPSC Class | 39121400 |
| UOM | EA |
| Vendor Product | GWPMEX1A |
| Body Material | Brass |
| For Use With | Unarmoured Cables |
| Finish | Nickel Plated |
| Hazardous Area Rating | Ex db I/IIC Ex eb I/IIC Ex ta IIIC |
| IP Rating | IP66/68 |
| Max. Sheath OD | 11.9 mm |
| Min. Sheath OD | 9 mm |
| Product Type | Cable Glands Hazardous Area |
| Protrusion Length | 49.6 mm |
| Seal Material | Neoprene |
| Thread Length | 13 mm |
| Thread Pitch | 1.5 mm |
| Thread Size | M20 x 1.5 mm |
| Width Across Flats | 25.6 mm |
| Width Across Corners | 29.7 mm |
Description
Nickel plated brass cable glands for use with circular unarmoured cables to secure the cable and to provide an Explosion Protected, Weatherproof and Dust Excluding Ignition Proof entry into panels or enclosures that meet these requirements. The cable glands in this range are suitable for use in machine and equipment applications where an Explosion Protected, unarmoured, Weatherproof gland type termination is required.
