SMA Sunny Tripower Solar Inverter 2 MPPT Three Phase 10kW TS4 & RS485 Communication

SMA Sunny Tripower Solar Inverter 2 MPPT Three Phase 10kW TS4 & RS485 Communication

In stock
SKU
SSTSTP10.0-3AV-40
Add to Compare
main product photo
Solar Inverter, 3 Phase, 15000 Watt Input, 1000 Volt DC Input, 580 Volt DC Nominal, 320-800 Volt DC MPPT Voltage Range, 150 Volt DC Start-up, 20 Amp/12 Amp Max. Input, 2 MPPTs, 10 kW Output, 10000 VA Max. Apparent, 180-280 Volt AC Operating, 220/415 Volt, 3/N/PE AC Nominal, 50 Hz, 3 x 14.5 Amp Output, 1, Adjustable- 0.8 Overexcited to 0.8 Underexcited Power Factor, 98.3% Efficiency, Transformerless, WLAN/Ethernet/RS485, Smartphone, Tablet, Laptop Display, Convection Cooling, 30 dBA, SUNCLIX/AC Connector, IP65, 4K4H Climate Category, -25 to 60 deg C, 100% Relative Humidity, 460 mm Width x 497 mm Height x 176 mm Depth, 20.5 kg
More Information
More Information
Features
  • One-person installation due to low weight of 20.5 kg
  • Compact design means minimum space requirements
  • 100% plug and play installation
  • Free online monitoring via sunny places
  • Automated service thanks to SMA smart connected
  • Use of surplus energy through dynamic active power limitation
  • Yield increase without installation effort due to integrated shade management SMA ShadeFix
  • Intelligent energy management and storage solutions can be added anytime
  • Can be combined with TS4-R components for module optimization
Brand SMA
Range Name Sunny Tripower
Standard Pack Size 16
UNSPSC Class 26111600
UOM EA
Vendor Product STP10.0-3AV-40
AC Max. Apparent Power 10000 VA
AC Nominal Voltage 220-415 Volt-3/N/PE
AC Operating Frequency 50 Hz
Cooling Method Convection
Connection Type SUNCLIX/AC Connector
AC Output Power 10 kW
AC Output Current 3 x 14.5 Amp
Climate Category 4K4H
AC Operating Voltage 180-280 Volt
Communication Port WLAN/Ethernet/RS485
DC Input Power 15000 Watt
DC Input Voltage 1000 Volt
DC Nominal Voltage 580 Volt
DC Max. Input Current 20-12 Amp
Depth 176 mm
DC MPPT Voltage Range 320-800 Volt
Display Type Smartphone/Tablet/Laptop
Efficiency 98.30%
DC Start-up Voltage 150 Volt
European Weighted Efficiency 98%
Height 497 mm
IP Rating IP65
Noise Level 30 dBA
Number of MPPTs 2
Operating Temperature -25 to 60 deg C
Phase 3 Phase
Product Type Inverters
Power Factor 1/Adjustable-0.8 Overexcited to 0.8 Underexcited
Relative Humidity 100%
Topology Transformerless
Width 460 mm

Description

Solar Inverter, 3 Phase, 15000 Watt Input, 1000 Volt DC Input, 580 Volt DC Nominal, 320-800 Volt DC MPPT Voltage Range, 150 Volt DC Start-up, 20 Amp/12 Amp Max. Input, 2 MPPTs, 10 kW Output, 10000 VA Max. Apparent, 180-280 Volt AC Operating, 220/415 Volt, 3/N/PE AC Nominal, 50 Hz, 3 x 14.5 Amp Output, 1, Adjustable- 0.8 Overexcited to 0.8 Underexcited Power Factor, 98.3% Efficiency, Transformerless, WLAN/Ethernet/RS485, Smartphone, Tablet, Laptop Display, Convection Cooling, 30 dBA, SUNCLIX/AC Connector, IP65, 4K4H Climate Category, -25 to 60 deg C, 100% Relative Humidity, 460 mm Width x 497 mm Height x 176 mm Depth, 20.5 kg

Infosheets
