Schneider Miniature Circuit Breaker D Curve 100Amp 15 kA 3Pole 4.5Module 81mm DIN 35mm Rail Mount
Schneider Miniature Circuit Breaker D Curve 100Amp 15 kA 3Pole 4.5Module 81mm DIN 35mm Rail Mount
In stock
SKU
SHNA9N18513
Miniature Circuit Breaker D Curve, 380-415-220-240-440/230-400 Volt AC/<=375 Volt DC, 100 Amp, 50/60 Hz, 15 kA Interrupt Capacity, 4.5 Module 81 mm, 3 Pole, Toggle Actuator, 3.5 Nm Top/Bottom Tightening Torque, Tunnel Terminal, 1.5-35 sq-mm Flexible/1-50 sq-mm Rigid, IP20, DIN Rail Mounting, White, 30 to 60 deg C, 81 mm Height, 81 mm Width, 73 mm Depth
| Brand | Schneider |
|---|---|
| Range Name | Acti 9 iC120H |
| Standard Pack Size | 1 |
| UNSPSC Class | 39121600 |
| UOM | EA |
| Vendor Product | A9N18513 |
| Actuator Type | Toggle |
| Cable Size | 1.5-35 sq-mm Flexible / 1-50 sq-mm Rigid |
| Colour | White |
| Current | 100 Amp |
| Depth | 73 mm |
| Frequency | 50/60 Hz |
| Height | 81 mm |
| Interrupt Capacity | 15 kA |
| IP Rating | IP20 |
| Modules | 4.5 Module 81 mm |
| Mounting Method | DIN Rail |
| Number Of Poles | 3 Pole |
| Product Type | Mini Circuit Breakers |
| Temperature | 30 to 60 deg C |
| Terminal Type | Tunnel |
| Tightening Torque | 3.5 Nm |
| Width | 81 mm |
Description
Miniature Circuit Breaker D Curve, 380-415-220-240-440/230-400 Volt AC/<=375 Volt DC, 100 Amp, 50/60 Hz, 15 kA Interrupt Capacity, 4.5 Module 81 mm, 3 Pole, Toggle Actuator, 3.5 Nm Top/Bottom Tightening Torque, Tunnel Terminal, 1.5-35 sq-mm Flexible/1-50 sq-mm Rigid, IP20, DIN Rail Mounting, White, 30 to 60 deg C, 81 mm Height, 81 mm Width, 73 mm Depth
