Radox R125 High Temperature Flexible Wire Single Insulated 1 Core 10mm 0.6/1kV XLPO Blue

Radox R125 High Temperature Flexible Wire Single Insulated 1 Core 10mm 0.6/1kV XLPO Blue

In stock
SKU
RADR125/10/BLU
Add to Compare
main product photo
Flexible Wire, Single Insulated, High Temperature, 1 Core, 10 mm, Stranded Tinned Copper, 0.6/1 kV, 78/0.4 mm Strands, 6.2 mm Overall Diameter, LSZH XLPO Insulation, Unsheathed, Blue Insulation, -40 to 125 deg C
More Information
More Information
Features
  • High current carrying capacities
  • Electron beam crosslinked
  • Short circuit temperatures of up to 280 deg C with no change to material properties
  • Easy processability (removal of insulation etc.)
  • Excellent resistance against all conventional impregnating varnishes and potting resins
  • Flexible
  • Good abrasion resistance and mechanical properties
  • Good resistance to ozone, UV and sunlight radiation
  • Thermal Class B
Brand Radox
Range Name R125
Standard Pack Size 100
UNSPSC Class 26121600
UOM MTR
Vendor Product R125/10/BLU
Conductor Type Stranded Tinned Copper
Conductor Size 10 mm
Insulation Material LSZH XLPO
Insulation Colour Blue
Overall Diameter 6.2 mm
Number of Cores 1 Core
Product Type Flexible Cable High Temperature
Sheath Material Unsheathed
Stranding 78/0.4 mm
Temperature -40 to 125 deg C
Voltage 0.6-1 kV

Description

Flexible Wire, Single Insulated, High Temperature, 1 Core, 10 mm, Stranded Tinned Copper, 0.6/1 kV, 78/0.4 mm Strands, 6.2 mm Overall Diameter, LSZH XLPO Insulation, Unsheathed, Blue Insulation, -40 to 125 deg C

Infosheets
