Panduit Ring Terminal Insulated Double Grip 8mm M12 Stud Red 41.6mm OAL
Panduit Ring Terminal Insulated Double Grip 8mm M12 Stud Red 41.6mm OAL
In stock
SKU
PANEV8-12R-Q
Ring Terminal, Insulated, Double Grip, Conductor Size: 8 mm, Stud Size: M12, Terminal Type: Circular, 600 Volt Maximum, Wire Strip Length: 11.9mm, Barrel Type: Standard, Seam Type: Brazed, Crimping Die: KST-HDC38A, Mounting Method: Free Hanging, Body Material: Copper, Insulation Material: Vinyl, Red Insulation, Tin Plated Finish, 221 deg F, 41.6mm Overall Length, 24.9mm Lug Length, 20.1mm Lug Width, 1.2mm Lug Thickness, 13mm Lug Inside Diameter, Barrel Length: 8.4mm, Max. Insulation Diameter: 8.1mm, 25 Pack
| Brand | Panduit |
|---|---|
| Range Name | StrongHold |
| Standard Pack Size | 25 |
| UNSPSC Class | 39121400 |
| UOM | EA |
| Vendor Product | EV8-12R-Q |
| Barrel Length | 8.4 mm |
| Barrel Type | Standard |
| Body Material | Copper |
| Conductor Size | 8mm |
| Crimping Die | KST-HDC38A |
| Finish | Tin Plated |
| Insulation Diameter | 8.1 mm |
| Insulation Colour | Red |
| Lug Inside Diameter | 13 mm |
| Insulation Material | Vinyl |
| Lug Length | 24.9 mm |
| Lug Thickness | 1.2 mm |
| Lug Width | 20.1 mm |
| Pack Size | 25 Pack |
| Mounting Method | Free Hanging |
| Overall Length | 41.6 mm |
| Product Type | Forked & Ring Terminals |
| Seam Type | Brazed |
| Stud Size | M12 Stud |
| Temperature | 221 deg F |
| Terminal Type | Circular |
| Voltage Rating | 600 Volt |
| Wire Strip Length | 11.9 mm |
Description
Ring Terminal, Insulated, Double Grip, Conductor Size: 8 mm, Stud Size: M12, Terminal Type: Circular, 600 Volt Maximum, Wire Strip Length: 11.9mm, Barrel Type: Standard, Seam Type: Brazed, Crimping Die: KST-HDC38A, Mounting Method: Free Hanging, Body Material: Copper, Insulation Material: Vinyl, Red Insulation, Tin Plated Finish, 221 deg F, 41.6mm Overall Length, 24.9mm Lug Length, 20.1mm Lug Width, 1.2mm Lug Thickness, 13mm Lug Inside Diameter, Barrel Length: 8.4mm, Max. Insulation Diameter: 8.1mm, 25 Pack
