Panduit Quick Connect Male Insulated Double Grip 1.5-2.5mm 4.8mm Tab Blue Vinyl
Panduit Quick Connect Male Insulated Double Grip 1.5-2.5mm 4.8mm Tab Blue Vinyl
In stock
SKU
PANEDV14-187MB-Q
QC Terminal, male, Insulated, Double Grip, Conductor Size: 1.5-2.5 mm, Tab Size: 4.8mm, Wire Strip Length: 7.1mm, Barrel Length: 12.5mm, Seam Type: Butted, 300 Volt Maximum, Crimping Die: KST2000C, Mounting Method: Free Hanging, Base Material: Copper, Conductive Material: Copper, Insulation Material: Vinyl, Blue Insulation, Tin Plated Finish, 75 deg C, Max. Wire Insulation Diameter: 4.2mm, 19mm Length, 4.8mm Width, Thickness: 0.4mm, 25 Pack
| Brand | Panduit |
|---|---|
| Range Name | StrongHold |
| Standard Pack Size | 25 |
| UNSPSC Class | 39121400 |
| UOM | EA |
| Vendor Product | EDV14-187MB-Q |
| Barrel Length | 12.5 mm |
| Base Material | Copper |
| Conductive Material | Copper |
| Crimping Die | KST2000C |
| Finish | Tin Plated |
| Insulation Colour | Blue |
| Length | 19 mm |
| Insulation Material | Vinyl |
| Mounting Method | Free Hanging |
| Pack Size | 25 Pack |
| Product Type | Quick Connect Terminals |
| Seam Type | Butted |
| Tab Size | 4.8 mm |
| Thickness | 0.4 mm |
| Temperature | 75 deg C |
| Voltage Rating | 300 Volt |
| Width | 4.8 mm |
| Wire Strip Length | 7.1 mm |
| Wire Insulation Diameter | 4.2 mm |
Description
QC Terminal, male, Insulated, Double Grip, Conductor Size: 1.5-2.5 mm, Tab Size: 4.8mm, Wire Strip Length: 7.1mm, Barrel Length: 12.5mm, Seam Type: Butted, 300 Volt Maximum, Crimping Die: KST2000C, Mounting Method: Free Hanging, Base Material: Copper, Conductive Material: Copper, Insulation Material: Vinyl, Blue Insulation, Tin Plated Finish, 75 deg C, Max. Wire Insulation Diameter: 4.2mm, 19mm Length, 4.8mm Width, Thickness: 0.4mm, 25 Pack
