Olex 16mm SDI Cable Red 100mtr
Olex 16mm SDI Cable Red 100mtr
In stock
SKU
OLX7/170-1RA1
SDI Cable, 16 mm, Stranded Copper, 450-750 Volt, 1 Core, 7/1.7 mm Strands, 8.9 mm Overall Diameter, 100 mtr Length, 53 mm Bend Radius, 1 mm Insulation Thickness, 1 mm Sheath Thickness, DC: 1.15 Ohm/km AC: 1.4 Ohm/km Conductor Resistance, 6 MOhm/km Insulation Resistance, Red Core, V-90 PVC Insulation, PVC Sheath, White Sheath, 90 deg C, AS/NZS 1125 AS/NZS 5000.1 AS/NZS 5000.2
| Brand | Olex |
|---|---|
| Standard Pack Size | 100 |
| UNSPSC Class | 26121600 |
| UOM | MTR |
| Vendor Product | AABP15A1001WVRD |
| Bend Radius | 53 mm |
| Conductor Resistance | DC: 1.15 Ohm/km AC: 1.4 Ohm/km |
| Conductor Size | 16 mm |
| Conductor Type | Stranded Copper |
| Core Colours | Red |
| Insulation Material | V-90 PVC |
| Insulation Resistance | 6 MOhm/km |
| Insulation Thickness | 1 mm |
| Length | 100 mtr |
| Number of Cores | 1 Core |
| Overall Diameter | 8.9 mm |
| Product Type | SDI Cable |
| Sheath Colour | White |
| Sheath Material | PVC |
| Sheath Thickness | 1 mm |
| Standards | AS/NZS 1125 AS/NZS 5000.1 AS/NZS 5000.2 |
| Stranding | 7/1.7 mm |
| Temperature | 90 deg C |
| Voltage | 450-750 Volt |
Description
SDI Cable, 16 mm, Stranded Copper, 450-750 Volt, 1 Core, 7/1.7 mm Strands, 8.9 mm Overall Diameter, 100 mtr Length, 53 mm Bend Radius, 1 mm Insulation Thickness, 1 mm Sheath Thickness, DC: 1.15 Ohm/km AC: 1.4 Ohm/km Conductor Resistance, 6 MOhm/km Insulation Resistance, Red Core, V-90 PVC Insulation, PVC Sheath, White Sheath, 90 deg C, AS/NZS 1125 AS/NZS 5000.1 AS/NZS 5000.2
