Olex Varolex Rigid VSD/EMC Cable Screened 3 Core & 3 Earth 35mm 0.6/1kV Stranded Copper XLPE/Copper Tape/PVC Black
Olex Varolex Rigid VSD/EMC Cable Screened 3 Core & 3 Earth 35mm 0.6/1kV Stranded Copper XLPE/Copper Tape/PVC Black
In stock
SKU
OLX19/153-3EVAA9
VSD/EMC Cable Rigid, 35 mm, Stranded Copper, 0.6-1 kV, 3 Core + 3 Earth, 19/1.53 mm Strands, 26.1 mm Overall Diameter, 6 mm Earth Conductor, 470 mm During Installation/315 mm After Installation Bend Radius, 0.9 mm Insulation Thickness, 3.13 kN Pulling Tension, DC: 0.524 Ohm/km AC: 0.669 Ohm/km Conductor Resistance, 430 MOhm/km Insulation Resistance, Copper Braid Screen, Red/Blue/White/Green/Yellow Core, X-90 XLPE Insulation, PVC Sheath, Black Sheath, 90 deg C, AS/NZS 1125 AS/NZS 5000.1
| Brand | Olex |
|---|---|
| Standard Pack Size | 1 |
| UNSPSC Class | 26121600 |
| UOM | MTR |
| Vendor Product | FTDC18AA003CXRJ |
| Bend Radius | 470 mm During Installation/315 mm After Installation |
| Conductor Resistance | DC: 0.524 Ohm/km AC: 0.669 Ohm/km |
| Conductor Size | 35 mm |
| Conductor Type | Stranded Copper |
| Core Colours | Red/Blue/White/Green/Yellow |
| Earth Conductor Size | 6 mm |
| Insulation Material | X-90 XLPE |
| Insulation Resistance | 430 MOhm/km |
| Insulation Thickness | 0.9 mm |
| Number of Cores | 3 Core + Earth |
| Overall Diameter | 26.1 mm |
| Product Type | VSD/EMC Cable Rigid |
| Pulling Tension | 3.13 kN |
| Screen Material | Copper Braid |
| Sheath Colour | Black |
| Sheath Material | PVC |
| Standards | AS/NZS 1125 AS/NZS 5000.1 |
| Stranding | 19/1.53 mm |
| Temperature | 90 deg C |
| Voltage | 0.6-1 kV |
Description
VSD/EMC Cable Rigid, 35 mm, Stranded Copper, 0.6-1 kV, 3 Core + 3 Earth, 19/1.53 mm Strands, 26.1 mm Overall Diameter, 6 mm Earth Conductor, 470 mm During Installation/315 mm After Installation Bend Radius, 0.9 mm Insulation Thickness, 3.13 kN Pulling Tension, DC: 0.524 Ohm/km AC: 0.669 Ohm/km Conductor Resistance, 430 MOhm/km Insulation Resistance, Copper Braid Screen, Red/Blue/White/Green/Yellow Core, X-90 XLPE Insulation, PVC Sheath, Black Sheath, 90 deg C, AS/NZS 1125 AS/NZS 5000.1
