Lovato Contactor General Purpose AC Operated 3 Pole 10kW 12A AC3 25A AC1 24V 1NC Auxilary DIN Rail/Base Mount
Lovato Contactor General Purpose AC Operated 3 Pole 10kW 12A AC3 25A AC1 24V 1NC Auxilary DIN Rail/Base Mount
In stock
SKU
LOVBF1201A024
Contactor General Purpose AC Operated, 24 Volt AC, AC3 Rating (kW): 10 at 55 deg C, AC3 Rating (Amps): 12, AC1 Rating (Amps): 25, 690 Volt, 1NC Auxiliary, 3 Pole, Screw Terminal, DIN Rail/Base Mount, IP20, -50 to 70 deg C, 126 mm Height, 45 mm Width, 80.7 mm Depth
| Features |
|
|---|---|
| Brand | Lovato |
| Range Name | Orange BF |
| Standard Pack Size | 1 |
| UNSPSC Class | 39121500 |
| UOM | EA |
| Vendor Product | LOVBF1201A024 |
| AC1 Rating (Amps) | 25 Amp AC1 |
| AC3 Rating (Amps) | 12 Amp AC3 |
| AC3 Rating (kW) | 10 kW |
| Contact Voltage | 690 Volt |
| Contact Configuration | 1 Normally Closed Aux |
| Depth | 80.7 mm |
| Height | 126 mm |
| IP Rating | IP20 |
| Mounting Method | DIN Rail/Base |
| Number Of Poles | 3 Pole |
| Operating Coil Voltage | 24 Volt AC |
| Product Type | Contactors General |
| Temperature | -50 to 70 deg C |
| Terminal Connection | Screw |
| Width | 45 mm |
Description
Contactor General Purpose AC Operated, 24 Volt AC, AC3 Rating (kW): 10 at 55 deg C, AC3 Rating (Amps): 12, AC1 Rating (Amps): 25, 690 Volt, 1NC Auxiliary, 3 Pole, Screw Terminal, DIN Rail/Base Mount, IP20, -50 to 70 deg C, 126 mm Height, 45 mm Width, 80.7 mm Depth
