Legrand Miniature Circuit Breaker C Curve 20Amp 10 kA 3Pole 3Module 53.1mm DIN Rail Mount
Legrand Miniature Circuit Breaker C Curve 20Amp 10 kA 3Pole 3Module 53.1mm DIN Rail Mount
In stock
SKU
LEG409255
Miniature Circuit Breaker C Curve C Curve, 240/415 Volt, 20 Amp, 50/60 Hz, Interrupt Capacity: 10 kA, Number of Modules: 3, 53.1mm Module Width, Number of Poles: 3, 3, Trip Characteristic: C Curve, 2 Position Handle Actuator, 2 N/m Mini, 3 N/m Maxi Tightening Torque, 1.5-35 mm Flexible/1.5-25 mm Rigid Cable Terminal Capacity, IP20, IP40, DIN Rail, Polyester Housing,-25 to 70 deg C, 83mm Height x 53.1mm Width x 77.8mm Depth
| Features |
|
|---|---|
| Brand | Legrand |
| Standard Pack Size | 1 |
| UNSPSC Class | 39121600 |
| UOM | EA |
| Vendor Product | 409255 |
| Actuator Type | 2 Position Handle |
| Current | 20 Amp |
| Depth | 77.8 mm |
| Frequency | 50/60 Hz |
| Height | 83 mm |
| Interrupt Capacity | 10 kA |
| IP Rating | IP20/40 |
| Modules | 3 Module 53.1mm |
| Mounting Method | DIN Rail |
| Number Of Poles | 3 Pole |
| Phase | 3 Phase |
| Product Type | Mini Circuit Breakers |
| Temperature | -25 to 70 deg C |
| Tightening Torque | 2 Nm Mini/3 Nm Maxi |
| Voltage | 240-415 Volt |
| Width | 53.1 mm |
Description
Miniature Circuit Breaker C Curve C Curve, 240/415 Volt, 20 Amp, 50/60 Hz, Interrupt Capacity: 10 kA, Number of Modules: 3, 53.1mm Module Width, Number of Poles: 3, 3, Trip Characteristic: C Curve, 2 Position Handle Actuator, 2 N/m Mini, 3 N/m Maxi Tightening Torque, 1.5-35 mm Flexible/1.5-25 mm Rigid Cable Terminal Capacity, IP20, IP40, DIN Rail, Polyester Housing,-25 to 70 deg C, 83mm Height x 53.1mm Width x 77.8mm Depth
