Legrand Mains Isolating Switch 3P 100A 400V 2C/O Busbar DIN Rail Mount
Legrand Mains Isolating Switch 3P 100A 400V 2C/O Busbar DIN Rail Mount
In stock
SKU
LEG406469
Mains Isolating Switch, 400 V, 100 Amp, 50/60 Hz, 3 Poles, 3 Modules, 53.1mm Module Width, 2C/O, 4-35 mm Flexible, 4-50 mm Rigid Conductor, Busbar, IP20, DIN Rail, Plastic, Grey Handle,-25 to 70 deg C, 94.8mm Height x 70.2mm Depth
| Brand | Legrand |
|---|---|
| Range Name | Lexic DX3 |
| Standard Pack Size | 1 |
| UNSPSC Class | 39121300 |
| UOM | EA |
| Vendor Product | 406469 |
| Contact Configuration | 2 Changeover |
| Colour | Grey Handle |
| Conductor Size | 4-35 sq-mm Flexible/4-50 sq-mm Rigid |
| Dimensions | 94.8mm Height x 70.2mm Depth |
| Connection Type | Busbar |
| Current | 100 Amp |
| Frequency | 50/60 Hz |
| IP Rating | IP20 |
| Material | Plastic |
| Mounting Method | DIN Rail |
| Number Of Poles | 3 Pole |
| Modules | 3 Module 53.1mm |
| Product Type | Mains Switches |
| Temperature | -25 to 70 deg C |
| Voltage | 400 Volt |
Description
Mains Isolating Switch, 400 V, 100 Amp, 50/60 Hz, 3 Poles, 3 Modules, 53.1mm Module Width, 2C/O, 4-35 mm Flexible, 4-50 mm Rigid Conductor, Busbar, IP20, DIN Rail, Plastic, Grey Handle,-25 to 70 deg C, 94.8mm Height x 70.2mm Depth
