Lapp Kabel 1.5mm 4 Pair Instrumentation Cable Unarmoured Individual & Overall Screened
Lapp Kabel 1.5mm 4 Pair Instrumentation Cable Unarmoured Individual & Overall Screened
In stock
SKU
LAP1271162
Instrumentation Cable, Unarmoured, 1.5 mm, Annealed Copper, 0.5 kV, 4 Pair, Individual & Overall Screened Screen, 15.8 mm Overall Diameter, 94.8 mm Bend Radius, >10 MOhm/km Insulation Resistance, Aluminium/Polyester Tape Screen, Black/White Numerals Core, V-90HT PVC Insulation, 5V-90 PVC Sheath, Black Sheath, -30 to 105 deg C, EN 50288-7 IEC 60332-3-24
| Brand | Lapp Kabel |
|---|---|
| Standard Pack Size | 1 |
| UNSPSC Class | 26121600 |
| UOM | MTR |
| Vendor Product | 1271162 |
| Conductor Size | 1.5 mm |
| Conductor Type | Annealed Copper |
| Bend Radius | 94.8 mm |
| Core Colours | Black/White Numerals |
| Insulation Resistance | >10 MOhm/km |
| Insulation Material | V-90HT PVC |
| Number of Pairs | 4 Pair |
| Overall Diameter | 15.8 mm |
| Product Type | Instrumentation Cable Unarmoured |
| Screen Material | Aluminium/Polyester Tape |
| Sheath Colour | Black |
| Screen Format | Individual & Overall Screened |
| Sheath Material | 5V-90 PVC |
| Standards | EN 50288-7 IEC 60332-3-24 |
| Voltage | 0.5 kV |
| Temperature | -30 to 105 deg C |
Description
Instrumentation Cable, Unarmoured, 1.5 mm, Annealed Copper, 0.5 kV, 4 Pair, Individual & Overall Screened Screen, 15.8 mm Overall Diameter, 94.8 mm Bend Radius, >10 MOhm/km Insulation Resistance, Aluminium/Polyester Tape Screen, Black/White Numerals Core, V-90HT PVC Insulation, 5V-90 PVC Sheath, Black Sheath, -30 to 105 deg C, EN 50288-7 IEC 60332-3-24
