IME AC Ammeter Analogue Moving Iron Current Transformer 0-5A x 5 90Deg 70mm W DIN 35 Rail Mount
IME AC Ammeter Analogue Moving Iron Current Transformer 0-5A x 5 90Deg 70mm W DIN 35 Rail Mount
In stock
SKU
IMED4EACT5A2X5A
AC Ammeter Analogue Moving Iron, 0 to 5 Amp With x 2 Over-Scale, 5/10 Amp, 50/45-65 Hz, Current Transformer, 90 deg Deflection Accuracy Class 1.5, -25 to 50 deg C, Analogue Display, 89.5 mm Height x 70 mm Width, DIN 35 Rail Mount, Polycarbonate, 45 mm Height x 70 mm Width x 65.6 mm Depth
| Features |
|
|---|---|
| Brand | IME |
| Range Name | D4 |
| Standard Pack Size | 1 |
| UNSPSC Class | 41113600 |
| UOM | EA |
| Vendor Product | D4EACT5A2X5A |
| Current | 5/10 Amp |
| Depth | 65.6 mm |
| Display | Analogue |
| Frame Size | 89.5mm x 70mm |
| Frequency | 50/45-65 Hz |
| Height | 45 mm |
| Mounting Method | DIN Rail |
| Operation Form | Current Transformer |
| Product Type | Ammeters |
| Readout Form | 90 deg Deflection Accuracy Class 1.5 |
| Scale | 0 to 5 Amp with x2 Over-Scale |
| Temperature | -25 to 50 deg C |
| Width | 70 mm |
Description
AC Ammeter Analogue Moving Iron, 0 to 5 Amp With x 2 Over-Scale, 5/10 Amp, 50/45-65 Hz, Current Transformer, 90 deg Deflection Accuracy Class 1.5, -25 to 50 deg C, Analogue Display, 89.5 mm Height x 70 mm Width, DIN 35 Rail Mount, Polycarbonate, 45 mm Height x 70 mm Width x 65.6 mm Depth
