Hager Miniature Circuit Breaker D Curve 40Amp 10kA 1Pole 1Module 18mm DIN Rail Mount
Hager Miniature Circuit Breaker D Curve 40Amp 10kA 1Pole 1Module 18mm DIN Rail Mount
In stock
SKU
HAGNDN140A
Miniature Circuit Breaker D Curve, 230-400 Volt, 40 Amp, 50/60 Hz, 10 kA Interrupt Capacity, 1 Module 18 mm, 1 Pole, 2.8 Nm Tightening Torque, Screw Terminal, 1-25 sq-mm Flexible/1-35 sq-mm Rigid, IP20, DIN Rail Mounting, 60 deg C, 83 mm Height, 17.5 mm Width, 70 mm Depth
| Brand | Hager |
|---|---|
| Standard Pack Size | 1 |
| UNSPSC Class | 39121600 |
| UOM | EA |
| Vendor Product | NDN140A |
| Cable Size | 1-25 sq-mm Flexible/1-35 sq-mm Rigid |
| Current | 40 Amp |
| Depth | 70 mm |
| Frequency | 50/60 Hz |
| Height | 83 mm |
| Interrupt Capacity | 10 kA |
| IP Rating | IP20 |
| Modules | 1 Module 18 mm |
| Mounting Method | DIN Rail |
| Number Of Poles | 1 Pole |
| Product Type | Mini Circuit Breakers |
| Temperature | 60 deg C |
| Terminal Type | Screw |
| Tightening Torque | 2.8 Nm |
| Voltage | 230-400 Volt |
| Width | 17.5 mm |
Description
Miniature Circuit Breaker D Curve, 230-400 Volt, 40 Amp, 50/60 Hz, 10 kA Interrupt Capacity, 1 Module 18 mm, 1 Pole, 2.8 Nm Tightening Torque, Screw Terminal, 1-25 sq-mm Flexible/1-35 sq-mm Rigid, IP20, DIN Rail Mounting, 60 deg C, 83 mm Height, 17.5 mm Width, 70 mm Depth
