Hager Combination RCD Circuit Breaker RCBO 1P+N 13 Amp 230/240VAC 10 kA 2Module 36mm DIN Rail
Hager Combination RCD Circuit Breaker RCBO 1P+N 13 Amp 230/240VAC 10 kA 2Module 36mm DIN Rail
In stock
SKU
HAGACA563T
Combination RCD Circuit Breaker RCBO Type A, 13 Amp, 230/240 Volt AC, 50 Hz, Interrupt Capacity: 10 kA, Trip Sensitivity: 10 mA, Magnetic Rating: 5/10 In, Number of Poles: 1P + N, Number of Modules: 2, 36mm Module Width, Trip Characteristic: C Curve, 1-16 mm Flexible/1-25 mm Rigid Terminal Connection, Screw, IP20, DIN Rail, 83mm Height, 35mm Width, 68mm Depth
| Brand | Hager |
|---|---|
| Standard Pack Size | 1 |
| UNSPSC Class | 39121600 |
| UOM | EA |
| Vendor Product | ACA563T |
| Current | 13 Amp |
| Connection Type | Screw |
| Depth | 68 mm |
| Height | 83 mm |
| Frequency | 50 Hz |
| IP Rating | IP20 |
| Interrupt Capacity | 10 kA |
| Modules | 2 Module 36 mm |
| Mounting Method | DIN Rail |
| Number Of Poles | 1 Pole |
| Product Type | Combination RCBO |
| Terminal Connection | 1-16 sq-mm Flexible / 1-25 sq-mm Rigid |
| Trip Characteristic | C Curve |
| Voltage | 230-240 Volt |
| Trip Sensitivity | 10 mA |
| Width | 35 mm |
Description
Combination RCD Circuit Breaker RCBO Type A, 13 Amp, 230/240 Volt AC, 50 Hz, Interrupt Capacity: 10 kA, Trip Sensitivity: 10 mA, Magnetic Rating: 5/10 In, Number of Poles: 1P + N, Number of Modules: 2, 36mm Module Width, Trip Characteristic: C Curve, 1-16 mm Flexible/1-25 mm Rigid Terminal Connection, Screw, IP20, DIN Rail, 83mm Height, 35mm Width, 68mm Depth
