Garland 1.13mm 2 Core Cream Figure 8 Speaker Cable Double Insulated Polyethylene/PVC
Garland 1.13mm 2 Core Cream Figure 8 Speaker Cable Double Insulated Polyethylene/PVC
In stock
SKU
GARTSW2120500
Speaker Cable, Figure 8, Double Insulated, 1.13 mm, Annealed Copper, 2 Core, 1/1.2 mm Strands, 3 mm x 4.7 mm Overall Diameter, 30 mm Static Bend Radius, 0.3 mm Insulation Thickness, 0.5 mm Sheath Thickness, 158 N Pulling Tension, DC: 15.56 Ohm/km Conductor Resistance, 1000 MOhm/km Insulation Resistance, Polyethylene Insulation, Red/White Insulation, PVC Sheath, Cream Sheath, -15 to 70 deg C, AS/NZS 1125 AS/NZS 3808
| Brand | Garland |
|---|---|
| Standard Pack Size | 500 |
| UNSPSC Class | 26121600 |
| UOM | MTR |
| Vendor Product | TSW2120500 |
| Conductor Resistance | DC: 15.56 Ohm/km |
| Bend Radius | Static 30 mm |
| Conductor Size | 1.13 mm |
| Conductor Type | Annealed Copper |
| Insulation Colour | Red/White |
| Insulation Material | Polyethylene |
| Insulation Resistance | 1000 MOhm/km |
| Number of Cores | 2 Core |
| Insulation Thickness | 0.3 mm |
| Overall Diameter | 3 mm x 4.7 mm |
| Product Type | Speaker Cable Figure 8 Double Insulated |
| Pulling Tension | 158 N |
| Sheath Colour | Cream |
| Sheath Thickness | 0.5 mm |
| Sheath Material | PVC |
| Standards | AS/NZS 1125 AS/NZS 3808 |
| Stranding | 1/1.2 mm |
| Temperature | -15 to 70 deg C |
Description
Speaker Cable, Figure 8, Double Insulated, 1.13 mm, Annealed Copper, 2 Core, 1/1.2 mm Strands, 3 mm x 4.7 mm Overall Diameter, 30 mm Static Bend Radius, 0.3 mm Insulation Thickness, 0.5 mm Sheath Thickness, 158 N Pulling Tension, DC: 15.56 Ohm/km Conductor Resistance, 1000 MOhm/km Insulation Resistance, Polyethylene Insulation, Red/White Insulation, PVC Sheath, Cream Sheath, -15 to 70 deg C, AS/NZS 1125 AS/NZS 3808
