Garland Pro Series Flexible Wire 2 Core Figure 8 0.75mm 240V Plain Annealed Copper PVC/PVC White
Garland Pro Series Flexible Wire 2 Core Figure 8 0.75mm 240V Plain Annealed Copper PVC/PVC White
In stock
SKU
GARTSCW24WH500
Flexible Cable Figure 8, 0.75 mm, Annealed Copper, 240 Volt, 2 Core, 24/0.2 mm Strands, Static 33 mm Bend Radius, 0.5 mm Insulation Thickness, 0.5 mm Sheath Thickness, Insulation: >100% Sheath: >100% Elongation, 105 N Pulling Tension, Before Aging: >12 MPa Tensile Strength, DC: 29.1 Ohm/km Conductor Resistance, 50 MOhm/km Insulation Resistance, Red/White Core, V-75 PVC Insulation, 4V-75 PVC Sheath, White Sheath, -15 to 75 deg C, AS/ACIF S008 AS 1049
| Brand | Garland |
|---|---|
| Standard Pack Size | 500 |
| UNSPSC Class | 26121600 |
| UOM | MTR |
| Vendor Product | TSCW24WH500 |
| Bend Radius | Static 33 mm |
| Conductor Resistance | 29.1 Ohm/km |
| Conductor Size | 0.75 mm |
| Conductor Type | Annealed Copper |
| Core Colours | Red/White |
| Elongation | Insulation: >100% Sheath: >100% |
| Insulation Material | V-75 PVC |
| Insulation Resistance | 50 MOhm/km |
| Insulation Thickness | 0.5 mm |
| Number of Cores | 2 Core |
| Product Type | Flexible Cable Figure 8 |
| Pulling Tension | 105 N |
| Sheath Colour | White |
| Sheath Material | 4V-75 PVC |
| Sheath Thickness | 0.5 mm |
| Standards | AS/ACIF S008 AS 1049 |
| Stranding | 24/0.2 mm |
| Temperature | -15 to 75 deg C |
| Tensile Strength | Before Aging: >12 MPa |
| Voltage | 240 Volt |
Description
Flexible Cable Figure 8, 0.75 mm, Annealed Copper, 240 Volt, 2 Core, 24/0.2 mm Strands, Static 33 mm Bend Radius, 0.5 mm Insulation Thickness, 0.5 mm Sheath Thickness, Insulation: >100% Sheath: >100% Elongation, 105 N Pulling Tension, Before Aging: >12 MPa Tensile Strength, DC: 29.1 Ohm/km Conductor Resistance, 50 MOhm/km Insulation Resistance, Red/White Core, V-75 PVC Insulation, 4V-75 PVC Sheath, White Sheath, -15 to 75 deg C, AS/ACIF S008 AS 1049
