Garland 0.75mm 2 Core Blue Figure 8 Fire Alarm Cable Double Insulated PVC/PVC
Garland 0.75mm 2 Core Blue Figure 8 Fire Alarm Cable Double Insulated PVC/PVC
In stock
SKU
GARTSCW24BL100
Fire Alarm Cable, Figure 8, Double Insulated, 0.75 mm, Annealed Copper, 240 Volt, 2 Core, 24/0.2 mm Strands, 3.3 mm x 5.4 mm Overall Diameter, 33 mm Static Bend Radius, 0.5 mm Insulation Thickness, 0.5 mm Sheath Thickness, 105 N Pulling Tension, DC: 29.1 Ohm/km Conductor Resistance, 50 MOhm/km Insulation Resistance, V-75 PVC Insulation, Red/White Insulation, 4V-75 PVC Sheath, Blue Sheath, -15 to 75 deg C, AS/ACIF S008 AS 1049
| Brand | Garland |
|---|---|
| Standard Pack Size | 100 |
| UNSPSC Class | 26121600 |
| UOM | MTR |
| Vendor Product | TSCW24BL100 |
| Conductor Resistance | DC: 29.1 Ohm/km |
| Bend Radius | Static 33 mm |
| Conductor Size | 0.75 mm |
| Conductor Type | Annealed Copper |
| Insulation Colour | Red/White |
| Insulation Material | V-75 PVC |
| Insulation Resistance | 50 MOhm/km |
| Number of Cores | 2 Core |
| Insulation Thickness | 0.5 mm |
| Overall Diameter | 3.3 mm x 5.4 mm |
| Product Type | Fire Alarm Cable Figure 8 Double Insulated |
| Pulling Tension | 105 N |
| Sheath Colour | Blue |
| Sheath Thickness | 0.5 mm |
| Sheath Material | 4V-75 PVC |
| Standards | AS/ACIF S008 AS 1049 |
| Stranding | 24/0.2 mm |
| Temperature | -15 to 75 deg C |
| Voltage | 240 Volt |
Description
Fire Alarm Cable, Figure 8, Double Insulated, 0.75 mm, Annealed Copper, 240 Volt, 2 Core, 24/0.2 mm Strands, 3.3 mm x 5.4 mm Overall Diameter, 33 mm Static Bend Radius, 0.5 mm Insulation Thickness, 0.5 mm Sheath Thickness, 105 N Pulling Tension, DC: 29.1 Ohm/km Conductor Resistance, 50 MOhm/km Insulation Resistance, V-75 PVC Insulation, Red/White Insulation, 4V-75 PVC Sheath, Blue Sheath, -15 to 75 deg C, AS/ACIF S008 AS 1049
