Garland Pro Series Security Cable Unscreened 4 Core 0.44mm 14/0.2mm PVC/PVC Brown
Garland Pro Series Security Cable Unscreened 4 Core 0.44mm 14/0.2mm PVC/PVC Brown
In stock
SKU
GARMC144BN300B
Security Cable, Unscreened, 4 Core, 0.44 mm, Plain Annealed Copper, 14/0.2 mm Strands, 4.7 mm Overall Diameter, Bend Radius: Static: - 47 mm, 0.3 mm Insulation Thickness, 0.5 mm Sheath Thickness, Elongation: Insulation - >100%, Outer Sheath - >100%, 123 N Pulling Tension, Before Aging - >12 MPa Tensile Strength, Conductor Resistance: 45.2 Ohm/km, Insulation Resistance: 50 MOhm/km, PVC Insulation, PVC Sheath, Red Black White Blue Cores, Brown Sheath, -15 to 70 deg C, AS/ACIF S008, BS4737-3.30
| Brand | Garland |
|---|---|
| Standard Pack Size | 300 |
| UNSPSC Class | 26121600 |
| UOM | MTR |
| Vendor Product | MC144BN300B |
| Bend Radius | Static: 47 mm |
| Conductor Resistance | 45.2 Ohm/km |
| Conductor Size | 0.44 mm |
| Conductor Type | Annealed Copper |
| Elongation | Insulation: >100% Outer Sheath: >100% |
| Insulation Material | PVC |
| Insulation Resistance | 50 MOhm/km |
| Insulation Thickness | 0.3 mm |
| Number of Cores | 4 Core |
| Overall Diameter | 4.7 mm |
| Product Type | Security Cable |
| Pulling Tension | 123 N |
| Sheath Colour | Brown |
| Sheath Material | PVC |
| Sheath Thickness | 0.5 mm |
| Standards | AS/ACIF S008 BS3737-3.30 |
| Stranding | 14/0.2 mm |
| Temperature | -15 to 70 deg C |
| Tensile Strength | Before Aging: >12 MPa |
Description
Security Cable, Unscreened, 4 Core, 0.44 mm, Plain Annealed Copper, 14/0.2 mm Strands, 4.7 mm Overall Diameter, Bend Radius: Static: - 47 mm, 0.3 mm Insulation Thickness, 0.5 mm Sheath Thickness, Elongation: Insulation - >100%, Outer Sheath - >100%, 123 N Pulling Tension, Before Aging - >12 MPa Tensile Strength, Conductor Resistance: 45.2 Ohm/km, Insulation Resistance: 50 MOhm/km, PVC Insulation, PVC Sheath, Red Black White Blue Cores, Brown Sheath, -15 to 70 deg C, AS/ACIF S008, BS4737-3.30
