FTP Data Cable Cat5e 4P Screened 24AWG PE/PVC Grey 500M

Garland Pro Series FTP Data Cable Cat5e 4 Pair Screened 24AWG Polyethylene/PVC Grey 500M

In stock
SKU
GARFTP5EGY500

FTP Data Cable Cat5e 4 Pair Screened, 24 AWG/0.23 mm, 0.542mm Conductor Diameter, Stranding: 1/0.542mm, 93.8 Ohm/km at 20 deg C Conductor Resistance, 1000 MOhm.km at 20 deg C Insulation Resistance, 0.23mm Insulation Thickness, 0.6mm Sheath Thickness, 100% Screen Coverage, Cat5e Screened FTP Cable, 4 Pair, Bend Radius: Install: 65mm, 129 N Max. Pulling Force, PACW Conductor, PE Insulation, PVC Sheath, Al. Polyester Tape Screen, Grey Sheath,-15 to 70 deg C, 500 mtr Length, 6.5mm Outside Diameter
More Information
Brand Garland
Standard Pack Size 500
UNSPSC Class 43223300
UOM MTR
Vendor Product FTP5EGY500
Product Type Cat5E Cable
Max. Pulling Force 129 N
Pair Count 4 Pair
Sheath Material PVC
Stranding 1/0.542mm
Screen Material Al. Polyester Tape
Cable Type Cat5e Screened FTP
Sheath Thickness 0.6mm
Insulation Material PE
Length 500 mtr
Outside Diameter 6.5mm
Sheath Colour Grey
Bend Radius Install: 65mm
Insulation Resistance 1000 MOhm.km at 20 deg C
Insulation Thickness 0.23mm
Conductor Diameter 0.542mm
Conductor Size 24 AWG/0.23 mm
Conductor Resistance 93.8 Ohm/km at 20 deg C
Conductor Material PACW
Temperature -15 to 70 deg C

Description

FTP Data Cable Cat5e 4 Pair Screened, 24 AWG/0.23 mm, 0.542mm Conductor Diameter, Stranding: 1/0.542mm, 93.8 Ohm/km at 20 deg C Conductor Resistance, 1000 MOhm.km at 20 deg C Insulation Resistance, 0.23mm Insulation Thickness, 0.6mm Sheath Thickness, 100% Screen Coverage, Cat5e Screened FTP Cable, 4 Pair, Bend Radius: Install: 65mm, 129 N Max. Pulling Force, PACW Conductor, PE Insulation, PVC Sheath, Al. Polyester Tape Screen, Grey Sheath,-15 to 70 deg C, 500 mtr Length, 6.5mm Outside Diameter
