Finder Miniature Power Relay Plug-In 2P 2CO 16A 240V 8 Pin Flat
Finder Miniature Power Relay Plug-In 2P 2CO 16A 240V 8 Pin Flat
In stock
SKU
FID62.820040240VAC
Miniature Power Relay, 250 Volt AC, 240 Volt AC, 16 Amp, 0.8 kW, 8 Pin Flat, 2 Pole, 2CO, 8500 Ohm, Operating Time: 4 Breaking/11 Making ms, 100000 Cycles, Plug-In Mount, Silver Cadmium Oxide, -40 to 70 deg C, 68 mm Height, 38.2 mm Width, 35.8 mm Depth
| Features |
|
|---|---|
| Brand | Finder |
| Range Name | Series 62 |
| Standard Pack Size | 1 |
| UNSPSC Class | 39122300 |
| UOM | EA |
| Vendor Product | 62820040240VAC |
| Contact Configuration | 2 Changeover |
| Depth | 35.8 mm |
| Height | 68 mm |
| Current | 16 Amp |
| Mounting Method | Plug In |
| Contact Material | Silver Cadmium Oxide |
| Number Of Poles | 2 Pole |
| Operating Coil Voltage | 240 Volt AC |
| Operating Cycles | 100000 Cycles |
| Pin Configuration | 8 Pin Flat |
| Operating Time | 4 Breaking/11 Making ms |
| Power Rating | 0.8 kW |
| Resistance | 8500 Ohm |
| Temperature | -40 to 70 deg C |
| Voltage | 250 Volt AC |
| Product Type | Power Relays |
| Width | 38.2 mm |
Description
Miniature Power Relay, 250 Volt AC, 240 Volt AC, 16 Amp, 0.8 kW, 8 Pin Flat, 2 Pole, 2CO, 8500 Ohm, Operating Time: 4 Breaking/11 Making ms, 100000 Cycles, Plug-In Mount, Silver Cadmium Oxide, -40 to 70 deg C, 68 mm Height, 38.2 mm Width, 35.8 mm Depth
