Finder Miniature Power Relay Plug-In 2P 2CO 12A 24V 8 Pin Flat
Finder Miniature Power Relay Plug-In 2P 2CO 12A 24V 8 Pin Flat
In stock
SKU
FID56.32.005424VAC
Miniature Power Relay, 250 Volt AC, 24 Volt AC Coil Voltage, 12 Amp, 0.55 kW, 8 Pin Flat, 2 Pole, 2 Changeover Configuration, 190 Ohm, 3 ms Breaking/8 ms making Operating Time, 100000 Cycles, Plug-In Mounting, Silver Nickel (Ag/Ni) Contact, -40 to 70 deg C, 27.7 mm Height, 20.7 mm Width, 37.7 mm Depth, With PB plus/LED plus/Mechanical Indicator
| Features |
|
|---|---|
| Brand | Finder |
| Range Name | Series 56 |
| Standard Pack Size | 1 |
| UNSPSC Class | 39122300 |
| UOM | EA |
| Vendor Product | 5632005424VAC |
| Contact Configuration | 2 Changeover |
| Depth | 37.7 mm |
| Height | 27.7 mm |
| Current | 12 Amp |
| Mounting Method | Plug-In |
| Contact Material | Silver Nickel (Ag/Ni) |
| Number Of Poles | 2 Pole |
| Operating Coil Voltage | 24 Volt AC |
| Operating Cycles | 100000 Cycles |
| Pin Configuration | 8 Pin Flat |
| Operating Time | 3 ms Breaking/8 ms making |
| Please Note | With PB plus/LED plus/Mechanical Indicator |
| Power Rating | 0.55 kW |
| Resistance | 190 Ohm |
| Temperature | -40 to 70 deg C |
| Voltage | 250 Volt AC |
| Product Type | Power Relays |
| Width | 20.7 mm |
Description
Miniature Power Relay, 250 Volt AC, 24 Volt AC Coil Voltage, 12 Amp, 0.55 kW, 8 Pin Flat, 2 Pole, 2 Changeover Configuration, 190 Ohm, 3 ms Breaking/8 ms making Operating Time, 100000 Cycles, Plug-In Mounting, Silver Nickel (Ag/Ni) Contact, -40 to 70 deg C, 27.7 mm Height, 20.7 mm Width, 37.7 mm Depth, With PB plus/LED plus/Mechanical Indicator
