Flex Wire H/D 1C 4mm CU V90HT PVC Green/Yellow 0.6/1kV

Elcon Heavy Duty Flexible Wire Single Insulated 1 Core 4mm 0.6/1kV Tinned Annealed Copper V90HT PVC Green/Yellow

In stock
SKU
ELNFHDT15603GY100M

Flexible Wire, Single Insulated, Heavy Duty, 1 Core, 4 mm, Tinned Annealed Copper, 0.6/1 kV, 37 Amp, 56/0.3 mm Strands, 4.7 mm Overall Diameter, 1 mm Insulation Thickness, Insulation Resistance: 5.09 MOhm/m, V-90HT PVC Insulation, Unsheathed, Green/Yellow Insulation, 90 deg C
More Information
Features
  • RoHS Compliant
  • Excellent flexibility
  • UV resistant
  • 99.9% OFHC (Oxygen Free High Conductivity) Copper which does not show any brittleness
Brand Elcon Cables
Standard Pack Size 100
UNSPSC Class 26121500
UOM MTR
Vendor Product FHDT15603GY100M
Conductor Type Tinned Annealed Copper
Insulation Colour Green/Yellow
Current 37 Amp
Insulation Material V-90HT PVC
Insulation Thickness 1 mm
Insulation Resistance 5.09 MOhm/m
Overall Diameter 4.7 mm
Product Type Flexible Wire 1 Core
Sheath Material Unsheathed
Stranding 56/0.3 mm
Temperature 90 deg C
Voltage 0.6-1 kV
Conductor Size 4 mm
Number of Cores 1

Description

Flexible Wire, Single Insulated, Heavy Duty, 1 Core, 4 mm, Tinned Annealed Copper, 0.6/1 kV, 37 Amp, 56/0.3 mm Strands, 4.7 mm Overall Diameter, 1 mm Insulation Thickness, Insulation Resistance: 5.09 MOhm/m, V-90HT PVC Insulation, Unsheathed, Green/Yellow Insulation, 90 deg C
