Elcon Cables Figure 8 Solar Cable 2 Core 6mm 0.6/1kV XLPE/XLPE Black 500mtr

Elcon Cables Figure 8 Solar Cable 2 Core 6mm 0.6/1kV XLPE/XLPE Black 500mtr

In stock
SKU
ELNCSO-F8TUV6BM-5
Solar Cable Figure 8, 0.9-1.8 kV DC/0.6-1 kV AC, 6 mm, 2 Core, 5.3 mm x 10.8 mm Overall Diameter, 500 mtr Length, 43.2 mm Bend Radius, 3.39 mOhm/m at 20 deg C Conductor Resistance, Tinned Copper Conductor, Electron Beam XLPE Insulation, Electron Beam XLPE Sheath, Black Sheath, 120 deg C
More Information
Features
  • Excellent flexibility, Ezi tear webbing
  • Flame retardant, 120 deg C low smoke zero halogen
  • UV stabilised
  • TUV Rhineland approved
  • Metre marked
  • Compact design
Brand Elcon Cables
Standard Pack Size 500
UNSPSC Class 26121600
UOM MTR
Vendor Product F8TUV6B500M
Bend Radius 43.2 mm
Conductor Material Tinned Copper
Conductor Resistance 3.39 mOhm/m at 20 deg C
Conductor Size 6 mm
Insulation Material Electron Beam XLPE
Length 500 mtr
Overall Diameter 5.3 mm x 10.8 mm
Product Type Solar Cable Figure 8
Number of Cores 2 Core
Sheath Material Electron Beam XLPE
Sheath Colour Black
Voltage 0.9-1.8 kV DC/0.6-1 kV AC
Temperature 120 deg C

Description

Solar Cable Figure 8, 0.9-1.8 kV DC/0.6-1 kV AC, 6 mm, 2 Core, 5.3 mm x 10.8 mm Overall Diameter, 500 mtr Length, 43.2 mm Bend Radius, 3.39 mOhm/m at 20 deg C Conductor Resistance, Tinned Copper Conductor, Electron Beam XLPE Insulation, Electron Beam XLPE Sheath, Black Sheath, 120 deg C
