Helukabel JZ-500 Flexible Control Cable Unscreened 20 Core & Earth 0.75mm 0.3/0.5kV Copper PVC/PVC Grey
Helukabel JZ-500 Flexible Control Cable Unscreened 20 Core & Earth 0.75mm 0.3/0.5kV Copper PVC/PVC Grey
In stock
SKU
DKSCC21G0.75
Flexible Control Cable, Unscreened, 20 Core & Earth, 0.75 mm, BaredegCopper, 0.3/0.5 kV, 12.8 mm Overall Diameter, Bend Radius: Static - 51.2 mm Flexible - 96 mm, Insulation Resistance: 20 Mohm/km, PVC Insulation, PVC Sheath, Black with White Numbered Green/Yellow Cores, Grey RAL 7001 Sheath, Static - -40 to 80 deg C Flexible - -15 to 80 deg C, DIN VDE 0285-525-2-51, DIN EN 50525-2-51
| Features |
|
|---|---|
| Brand | Helukabel |
| Standard Pack Size | 1 |
| UNSPSC Class | 26121600 |
| UOM | MTR |
| Vendor Product | CC21G0.75 |
| Bend Radius | Static: 51.2 mm - Flexible: 96 mm |
| Conductor Size | 0.75 mm |
| Conductor Type | Bare Copper |
| Core Colours | Green/Yellow/Black/White Numerals |
| Insulation Material | PVC |
| Insulation Resistance | 20 Mohm/km |
| Overall Diameter | 12.8 mm |
| Number of Cores | 20 Core + Earth |
| Product Type | Flexible Control Cable |
| Sheath Colour | Grey |
| Sheath Material | PVC |
| Standards | DIN VDE 0285-525-2-51 DIN EN 50525-2-51 |
| Temperature | Static: -40 to 80 deg C Flexible: -15 to 80 deg C |
| Voltage | 0.3-0.5 kV |
Description
Flexible Control Cable, Unscreened, 20 Core & Earth, 0.75 mm, BaredegCopper, 0.3/0.5 kV, 12.8 mm Overall Diameter, Bend Radius: Static - 51.2 mm Flexible - 96 mm, Insulation Resistance: 20 Mohm/km, PVC Insulation, PVC Sheath, Black with White Numbered Green/Yellow Cores, Grey RAL 7001 Sheath, Static - -40 to 80 deg C Flexible - -15 to 80 deg C, DIN VDE 0285-525-2-51, DIN EN 50525-2-51
