Crouse Hinds Hazardous Area Cable Gland Armoured 27-33.5mm M32 IP66/67
Crouse Hinds Hazardous Area Cable Gland Armoured 27-33.5mm M32 IP66/67
In stock
SKU
CRUTWAE3M34
Hazardous Area Cable Gland, Armoured, M32, 20 mm Thread Length, 27 mm Min. Sheath OD, 33.5 mm Max. Sheath OD, 25 mm Max. Bedding OD, 1.6 mm Min. Armour Wire, 2 mm Max. Armour Wire, Exe, Ex tD, 47.6 mm Width Across Flats, 55 mm Width Across Corners, IP66/67, Brass Body, Nickel Plated Finish, 33.5 mm Overall Length
| Features |
|
|---|---|
| Brand | Crouse Hinds |
| Range Name | Terminator TWAE |
| Standard Pack Size | 10 |
| UNSPSC Class | 39121400 |
| UOM | EA |
| Vendor Product | TWAE3M34 |
| Body Material | Brass |
| Finish | Nickel Plated |
| Hazardous Area Rating | Exe Ex tD |
| IP Rating | IP66/67 |
| Max. Armour Wire | 2 mm |
| Max. Bedding OD | 25 mm |
| Max. Sheath OD | 33.5 mm |
| Min. Armour Wire | 1.6 mm |
| Min. Sheath OD | 27 mm |
| Overall Length | 33.5 mm |
| Product Type | Cable Glands Hazardous Area |
| Thread Length | 20 mm |
| Thread Size | M32 |
| Width Across Corners | 55 mm |
| Width Across Flats | 47.6 mm |
Description
Hazardous Area Cable Gland, Armoured, M32, 20 mm Thread Length, 27 mm Min. Sheath OD, 33.5 mm Max. Sheath OD, 25 mm Max. Bedding OD, 1.6 mm Min. Armour Wire, 2 mm Max. Armour Wire, Exe, Ex tD, 47.6 mm Width Across Flats, 55 mm Width Across Corners, IP66/67, Brass Body, Nickel Plated Finish, 33.5 mm Overall Length
