CMP Products Hazardous Area Cable Gland Armoured Barrier 66.7-78.4mm M75 IP68
CMP Products Hazardous Area Cable Gland Armoured Barrier 66.7-78.4mm M75 IP68
In stock
SKU
CMP75PX2KREX1RA5
Hazardous Area Cable Gland, Armoured, Barrier, M75, 15 mm Thread Length, 66.7 mm Min. Sheath OD, 78.4 mm Max. Sheath OD, 64.2 mm Max. Bedding OD, 2.5 mm Min. Armour Wire, 3 mm Max. Armour Wire, Exd IIC Gb, Exe IIC Gb, Ex nR IIC Gc, Ex ta IIIC Da, Exd I Mb, Exe I Mb, 100 mm Width Across Flats, 110 mm Width Across Corners, 140 Core, 88.3 mm Protrusion Length, IP68, Thermoset Elastomer Seal, Brass Body, Nickel Plated Finish, -60 to 85 deg C, 103.3 mm Overall Length
| Features |
|
|---|---|
| Brand | CMP Products |
| Standard Pack Size | 1 |
| UNSPSC Class | 39121400 |
| UOM | EA |
| Vendor Product | 75PX2KREX1RA5 |
| Body Material | Brass |
| Finish | Nickel Plated |
| Hazardous Area Rating | Exd IIC Gb Exe IIC Gb Ex nR IIC Gc Ex ta IIIC Da Exd I Mb Exe I Mb |
| IP Rating | IP68 |
| Max. Armour Wire | 3 mm |
| Max. Bedding OD | 64.2 mm |
| Min. Armour Wire | 2.5 mm |
| Number of Cores | 140 |
| Max. Sheath OD | 78.4 mm |
| Overall Length | 103.3 mm |
| Min. Sheath OD | 66.7 mm |
| Product Type | Cable Glands Hazardous Area |
| Protrusion Length | 88.3 mm |
| Temperature | -60 to 85 deg C |
| Seal Material | Thermoset Elastomer |
| Thread Size | M75 |
| Thread Length | 15 mm |
| Width Across Corners | 110 mm |
| Width Across Flats | 100 mm |
Description
Hazardous Area Cable Gland, Armoured, Barrier, M75, 15 mm Thread Length, 66.7 mm Min. Sheath OD, 78.4 mm Max. Sheath OD, 64.2 mm Max. Bedding OD, 2.5 mm Min. Armour Wire, 3 mm Max. Armour Wire, Exd IIC Gb, Exe IIC Gb, Ex nR IIC Gc, Ex ta IIIC Da, Exd I Mb, Exe I Mb, 100 mm Width Across Flats, 110 mm Width Across Corners, 140 Core, 88.3 mm Protrusion Length, IP68, Thermoset Elastomer Seal, Brass Body, Nickel Plated Finish, -60 to 85 deg C, 103.3 mm Overall Length
