CMP Products Metal Cable Gland Unarmoured General Purpose M75 61.1-68mm Nickel Plated Brass IP68
CMP Products Metal Cable Gland Unarmoured General Purpose M75 61.1-68mm Nickel Plated Brass IP68
In stock
SKU
CMP75A21RA5/A
Cable Gland Metal Unarmoured General Purpose, M75, 15 mm Thread Length, 61.1 mm Min. Sheath OD, 68 mm Max. Sheath OD, 84 mm Width Across Flats, 92.4 mm Width Across Corners, 32 mm Protrusion Length, IP68, Brass Body, CMP Thermosetting Rubber Seal, Nickel Plated, -60 to 130 deg C
| Features |
|
|---|---|
| Brand | CMP Products |
| Range Name | Type A2 |
| Standard Pack Size | 1 |
| UNSPSC Class | 39121400 |
| UOM | EA |
| Vendor Product | 75A21RA5/A |
| Body Material | Brass |
| Finish | Nickel Plated |
| IP Rating | IP68 |
| Max. Sheath OD | 68 mm |
| Min. Sheath OD | 61.1 mm |
| Protrusion Length | 32 mm |
| Seal Material | CMP Thermosetting Rubber |
| Temperature | -60 to 130 deg C |
| Thread Length | 15 mm |
| Thread Size | M75 |
| Width Across Corners | 92.4 mm |
| Width Across Flats | 84 mm |
Description
Cable Gland Metal Unarmoured General Purpose, M75, 15 mm Thread Length, 61.1 mm Min. Sheath OD, 68 mm Max. Sheath OD, 84 mm Width Across Flats, 92.4 mm Width Across Corners, 32 mm Protrusion Length, IP68, Brass Body, CMP Thermosetting Rubber Seal, Nickel Plated, -60 to 130 deg C
