CMP Products Strain Relief Cable Gland Unarmoured Industrial M20 5-10mm Nylon IP66/67/68/69/69K

CMP Products Strain Relief Cable Gland Unarmoured Industrial M20 5-10mm Nylon IP66/67/68/69/69K

In stock
SKU
CMP20STSP2TNL/A
The TSP polymer strain relief range of cable glands are suitable for use in industrial (safe) areas with unarmoured or braided cable when terminated inside the enclosure, and have a temperature rating of +100 deg c to -60 deg c. With the widest cable sealing range on the market, the TSP reduces the need to purchase a range of different sized cable glands for a project, reducing the overall cost. The TSP range meets the requirements of well-known cable gland standards including EN 62444 and IEC 62444.For more specific applications IP68 and IP69X ingress discs or plugs are available, as well as a flame retardant UL94 V-0 option.
More Information
Features
  • For use in industrial (safe) areas with unarmoured or braided cable when terminated inside the enclosure
  • Halogen and phosphorus free
  • Finger-locking seal provides superior cable retention and strain relief
  • Low weight with high stiffness and strength
  • Widest cable range take for any comparable cable gland
  • Anti-vibration technology prevents gland loosening in operation
Brand CMP Products
Standard Pack Size 25
UNSPSC Class 39121400
UOM BX
Vendor Product 20STSP2TNL/A
Body Material Nylon
For Use With Unarmoured and Braid Armour Cables
IP Rating IP66/67/68/69
Min. Sheath OD 5 mm
Max. Sheath OD 10 mm
Overall Length 15 mm
Product Type Cable Glands Unarmoured
Seal Material Thermoset Elastomer
Temperature -40 to 100 deg C
Thread Length 10 mm
Thread Size M20
Width Across Corners 26.2 mm
Width Across Flats 24 mm

Description

The TSP polymer strain relief range of cable glands are suitable for use in industrial (safe) areas with unarmoured or braided cable when terminated inside the enclosure, and have a temperature rating of +100 deg c to -60 deg c. With the widest cable sealing range on the market, the TSP reduces the need to purchase a range of different sized cable glands for a project, reducing the overall cost. The TSP range meets the requirements of well-known cable gland standards including EN 62444 and IEC 62444.For more specific applications IP68 and IP69X ingress discs or plugs are available, as well as a flame retardant UL94 V-0 option.
