CMP Products Flame Proof Cable Gland Armoured 6.1-13.1mm M20 IP68
CMP Products Flame Proof Cable Gland Armoured 6.1-13.1mm M20 IP68
In stock
SKU
CMP20S16T3CDS1RA5
Grooved Cone (X) is predominantly used for Wire Braid (e.g. GSWB, TCWB), Steel Tape Armour (STA, DSTA) and Aluminium Strip Armour (ASA) but is also suitable for Single Wire Armour (SWA), Aluminium Wire Armour (AWA) and Pliable Wire Armour (PWA) if the range is outside that of the Stepped Cone (W).
| Features |
|
|---|---|
| Brand | CMP Products |
| Range Name | Triton CDS T3CDS |
| Standard Pack Size | 1 |
| UNSPSC Class | 39121400 |
| UOM | EA |
| Vendor Product | 20S16T3CDS1RA5 |
| Body Material | Brass |
| Finish | Nickel Plated |
| Hazardous Area Rating | Exd IIC Gb, Exe IIC Gb, Ex nR IIC Gc, Ex ta IIIC Da, Exd I Mb, Exe I Mb |
| IP Rating | IP68 |
| Max. Armour Wire | 1.2 mm |
| Max. Bedding OD | 8.7 mm |
| Max. Sheath OD | 13.1 mm |
| Min. Armour Wire | 0.8 mm |
| Min. Sheath OD | 6.1 mm |
| Product Type | Cable Glands Hazardous Area |
| Protrusion Length | 78.7 mm |
| Seal Material | Thermoset Elastomer |
| Temperature | -60 to 30 deg C |
| Thread Length | 15 mm |
| Thread Size | M16 |
| Width Across Corners | 26.4 mm |
| Width Across Flats | 24 mm |
Description
Grooved Cone (X) is predominantly used for Wire Braid (e.g. GSWB, TCWB), Steel Tape Armour (STA, DSTA) and Aluminium Strip Armour (ASA) but is also suitable for Single Wire Armour (SWA), Aluminium Wire Armour (AWA) and Pliable Wire Armour (PWA) if the range is outside that of the Stepped Cone (W).
