CMP Products Cable Gland Unarmoured Barrier 6.5-14mm M20 IP68
CMP Products Cable Gland Unarmoured Barrier 6.5-14mm M20 IP68
In stock
SKU
CMP20PXSS2KREX1RA5
Hazardous Area Cable Gland Unarmoured Barrier Type, M20, 15 mm Thread Length, 6.5 mm Min. Sheath OD, 14 mm Max. Sheath OD, 12.9 mm Max. Bedding OD, 30 mm Width Across Flats, 33 mm Width Across Corners, For Use With Unarmoured and Braid Armour Cables, Exd, Exe, Ex nR, Ex ta, 11 Conductors, 54.2 mm Protrusion Length, IP68, Brass Body, Thermoset Elastomer Seal, Nickel Plated, 69.2 mm Overall Length, -60 to 85 deg C
| Features |
|
|---|---|
| Brand | CMP Products |
| Range Name | Type PXSS2K-REX |
| Standard Pack Size | 1 |
| UNSPSC Class | 39121400 |
| UOM | EA |
| Vendor Product | 20PXSS2KREX1RA5 |
| Body Material | Brass |
| Finish | Nickel Plated |
| For Use With | Unarmoured and Braid Armour Cables |
| Hazardous Area Rating | Exd, Exe, Ex nR, Ex ta |
| IP Rating | IP68 |
| Max. Bedding OD | 12.9 mm |
| Min. Sheath OD | 6.5 mm |
| Max. Sheath OD | 14 mm |
| Number of Conductors | 11 |
| Overall Length | 69.2 mm |
| Product Type | Cable Glands Hazardous Area |
| Protrusion Length | 54.2 mm |
| Seal Material | Thermoset Elastomer |
| Temperature | -60 to 85 deg C |
| Thread Length | 15 mm |
| Thread Size | M20 |
| Width Across Corners | 33 mm |
| Width Across Flats | 30 mm |
Description
Hazardous Area Cable Gland Unarmoured Barrier Type, M20, 15 mm Thread Length, 6.5 mm Min. Sheath OD, 14 mm Max. Sheath OD, 12.9 mm Max. Bedding OD, 30 mm Width Across Flats, 33 mm Width Across Corners, For Use With Unarmoured and Braid Armour Cables, Exd, Exe, Ex nR, Ex ta, 11 Conductors, 54.2 mm Protrusion Length, IP68, Brass Body, Thermoset Elastomer Seal, Nickel Plated, 69.2 mm Overall Length, -60 to 85 deg C
