Certech UTP Network Cable High Performance Cat6A 4 Pair 23AWG HDPE/LSZH Grey 305M
Certech UTP Network Cable High Performance Cat6A 4 Pair 23AWG HDPE/LSZH Grey 305M
In stock
SKU
CERNCC6ALSZHGREY
The CERTECH CAT 6A U/UTP cable consists of 4 x copper conductor twisted pairs separated by a pair divider for superior AXT performance, LSZH jacket and a strength member for improved pulling tension. CERTECH CAT 6A cabling solutions support data transmission speeds of up to 10 gigabits per second (10 Gbps). When combined with CERTECH CAT 6A jacks and installed by a CERTECH certified installer, the permanent links exceed the performance criteria outlined is AS 11801 (1-6) and certifiable through CERTECH's 25 years Certified Warranty Program.
| Features |
|
|---|---|
| Brand | Certech |
| Standard Pack Size | 1 |
| UNSPSC Class | 26121600 |
| UOM | EA |
| Vendor Product | NCC6ALSZHGREY |
| Bend Radius | 8 x OD/4 x OD |
| Cable Type | Cat 6A UTP |
| Conductor Diameter | 0.56 mm |
| Conductor Material | Bare copper |
| Conductor Resistance | 9.38 Ohm/100m |
| Conductor Size | 23 AWG |
| Elongation | >=150 - >=125 |
| Frequency Bandwidth | 500 MHz |
| Insulation Material | HDPE |
| Length | 305 mtr |
| Outside Diameter | 7.1 mm |
| Pair Count | 4 Pair |
| Sheath Colour | Grey |
| Sheath Material | LSZH |
| Sheath Thickness | 0.7 mm +/-0.05 mm |
| Stranding | Solid |
| Temperature | 40 to 75 deg C |
Description
The CERTECH CAT 6A U/UTP cable consists of 4 x copper conductor twisted pairs separated by a pair divider for superior AXT performance, LSZH jacket and a strength member for improved pulling tension. CERTECH CAT 6A cabling solutions support data transmission speeds of up to 10 gigabits per second (10 Gbps). When combined with CERTECH CAT 6A jacks and installed by a CERTECH certified installer, the permanent links exceed the performance criteria outlined is AS 11801 (1-6) and certifiable through CERTECH's 25 years Certified Warranty Program.
