CCG Metal Cable Gland Unarmoured General Purpose M16x1.5 1-6mm Nickel Plated Brass IP66/68
CCG Metal Cable Gland Unarmoured General Purpose M16x1.5 1-6mm Nickel Plated Brass IP66/68
In stock
SKU
CCG053500-16S
Cable Gland Metal Unarmoured General Purpose, M16 x 1.5 mm, 10 mm Thread Length, 1.5 mm, 1 mm Min. Sheath OD, 6 mm Max. Sheath OD, For Use With Unarmoured Cables, 18 mm Width Across Flats, 20 mm Width Across Corners, 20 Nm Torque Rating, IP66/68, Brass Body, Thermoset Elastomer Seal, Nickel Plated, -30 to 130 deg C, 30 mm Overall Length
| Features |
|
|---|---|
| Brand | CCG |
| Range Name | Type A2 |
| Standard Pack Size | 10 |
| UNSPSC Class | 39121400 |
| UOM | EA |
| Vendor Product | 053500-16S |
| Body Material | Brass |
| Finish | Nickel Plated |
| For Use With | Unarmoured Cables |
| IP Rating | IP66/68 |
| Max. Sheath OD | 6 mm |
| Overall Length | 30 mm |
| Min. Sheath OD | 1 mm |
| Seal Material | Thermoset Elastomer |
| Temperature | -30 to 130 deg C |
| Thread Length | 10 mm |
| Thread Pitch | 1.5 mm |
| Thread Size | M16 x 1.5 mm |
| Width Across Corners | 20 mm |
| Width Across Flats | 18 mm |
| Torque Rating | 20 Nm |
Description
Cable Gland Metal Unarmoured General Purpose, M16 x 1.5 mm, 10 mm Thread Length, 1.5 mm, 1 mm Min. Sheath OD, 6 mm Max. Sheath OD, For Use With Unarmoured Cables, 18 mm Width Across Flats, 20 mm Width Across Corners, 20 Nm Torque Rating, IP66/68, Brass Body, Thermoset Elastomer Seal, Nickel Plated, -30 to 130 deg C, 30 mm Overall Length
