1.5 mm Black Circular Control Cable Unarmoured V-90 PVC/5V-90 PVC 100mtr
1.5 mm Black Circular Control Cable Unarmoured V-90 PVC/5V-90 PVC 100mtr
In stock
SKU
CBL1.5/30CECONTROL
Circular Control Cable, Unarmoured, 1.5 mm, Annealed Copper, 0.6-1 kV, 30 Core + Earth, 7/0.5 mm Strands, 25.4 mm Overall Diameter, 1.5 mm Earth Conductor, 100 mtr Length, 0.8 mm Insulation Thickness, 1.8 mm Sheath Thickness, White Numerals/Green/Yellow Core, V-90 PVC Insulation, 5V-90 PVC Sheath, Black Sheath, 90 deg C, AS/NZS 5000.1
| Brand | Generic |
|---|---|
| Standard Pack Size | 100 |
| UNSPSC Class | 26121600 |
| UOM | MTR |
| Vendor Product | VCM105E30B5K1 |
| Conductor Size | 1.5 mm |
| Conductor Type | Annealed Copper |
| Core Colours | Green/Yellow/White Numerals |
| Earth Conductor Size | 1.5 mm |
| Insulation Material | V-90 PVC |
| Insulation Thickness | 0.8 mm |
| Length | 100 mtr |
| Number of Cores | 30 Core + Earth |
| Overall Diameter | 25.4 mm |
| Product Type | Circular Control Unarmoured |
| Sheath Colour | Black |
| Standards | AS/NZS 5000.1 |
| Sheath Thickness | 1.8 mm |
| Sheath Material | 5V-90 PVC |
| Stranding | 7/0.5 mm |
| Temperature | 90 deg C |
| Voltage | 0.6-1 kV |
Description
Circular Control Cable, Unarmoured, 1.5 mm, Annealed Copper, 0.6-1 kV, 30 Core + Earth, 7/0.5 mm Strands, 25.4 mm Overall Diameter, 1.5 mm Earth Conductor, 100 mtr Length, 0.8 mm Insulation Thickness, 1.8 mm Sheath Thickness, White Numerals/Green/Yellow Core, V-90 PVC Insulation, 5V-90 PVC Sheath, Black Sheath, 90 deg C, AS/NZS 5000.1
