Cabac Full Tension Copper Sleeve 7/1.35 10mm
Cabac Full Tension Copper Sleeve 7/1.35 10mm
In stock
SKU
CAAPT10
Full Tension Copper Sleeve, 10 mm, Number of Strands: 7/1.35, 200 MPa Tensile Strength, 1.738 uohm cm, 99.7% IACS Conductivity, 40% Ductile Rating, Annealed Copper, -55 to 100 deg C, 4.5mm Inside Diameter, 80 mm Length, A/F Hex Die: 8.2 mm, Crimping Die: M82-50, 4 Crimps
| Features |
|
|---|---|
| Brand | Cabac |
| Standard Pack Size | 1 |
| UNSPSC Class | 39121400 |
| UOM | EA |
| Vendor Product | PT10 |
| Conductivity | 99.7% IACS |
| Conductor Size | 10 mm |
| Crimping Die | M82-50 |
| Ductile Rating | 40% |
| Inside Diameter | 4.5 mm |
| Length | 80 mm |
| Number of Crimps | 4 |
| Number of Strands | 7/1.35 |
| Product Type | Tension Sleeves |
| Resistivity | 1.738 uohm cm |
| Tensile Strength | 200 MPa |
| Temperature | -55 to 100 deg C |
Description
Full Tension Copper Sleeve, 10 mm, Number of Strands: 7/1.35, 200 MPa Tensile Strength, 1.738 uohm cm, 99.7% IACS Conductivity, 40% Ductile Rating, Annealed Copper, -55 to 100 deg C, 4.5mm Inside Diameter, 80 mm Length, A/F Hex Die: 8.2 mm, Crimping Die: M82-50, 4 Crimps
