AFL Fibre Optic Patch Lead Duplex Single-Mode OS2 9um/125um SC-LC LSZH Yellow 1m
AFL Fibre Optic Patch Lead Duplex Single-Mode OS2 9um/125um SC-LC LSZH Yellow 1m
In stock
SKU
ATAD1SCLC1M-SA1-2L
Fibre Optic Patch Lead, Duplex Single-Mode, Connector A: SC, Connector B: LC, 2 Fibre Count, Single-Mode, Fibre Type: 9 um Fibre 125 um Buffer OS2, 900 um Buffer Diameter, 1 mtr Cord Length, 2mm OD, Attenuation: 0.5 dB/km at 1310/1550 nm, Insertion Loss: 0.25 dB at 1310/1550 nm, Return Loss: 55 dB at 1310/1550 nm, LSZH Sheath, Yellow Sheath,-20 to 60 deg C
| Features |
|
|---|---|
| Brand | AFL |
| Standard Pack Size | 1 |
| UNSPSC Class | 43223300 |
| UOM | EA |
| Vendor Product | D1SCLC1M-SA1-2L-NLA |
| Attenuation | 0.5 dB/km at 1310/1550 nm |
| Connector A | SC |
| Connector B | LC |
| Cord Length | 1 mtr |
| Fibre Mode | Single-Mode |
| Fibre Count | 2 |
| Insertion Loss | 0.25 dB at 1310/1550 nm |
| Outside Diameter | 2mm |
| Fibre Type | 9 um Fibre 125 um Buffer OS2 |
| Product Type | Patch Leads Fibre |
| Return Loss | 55 dB at 1310/1550 nm |
| Sheath Colour | Yellow |
| Sheath Material | LSZH |
| Temperature | -20 to 60 deg C |
Description
Fibre Optic Patch Lead, Duplex Single-Mode, Connector A: SC, Connector B: LC, 2 Fibre Count, Single-Mode, Fibre Type: 9 um Fibre 125 um Buffer OS2, 900 um Buffer Diameter, 1 mtr Cord Length, 2mm OD, Attenuation: 0.5 dB/km at 1310/1550 nm, Insertion Loss: 0.25 dB at 1310/1550 nm, Return Loss: 55 dB at 1310/1550 nm, LSZH Sheath, Yellow Sheath,-20 to 60 deg C
