Aflex Flexible: Cable VSD EMC Screened 3 Core & 3 Earth 150 mm 0.6/1kV XLPE/Tinned Copper Braid/NBR Black
Aflex Flexible: Cable VSD EMC Screened 3 Core & 3 Earth 150 mm 0.6/1kV XLPE/Tinned Copper Braid/NBR Black
In stock
SKU
AFL777804150SC
Flexible: Cable, VSD EMC Screened, 3 Core & 3 Earth, 150 mm, Bare Annealed Copper, 0.6/1 kV, 375 Amp, 25 mm Earth Conductor, 58.5 mm Overall Diameter, Bend Radius: Static - 438.75 mm Flexible: 58.5 mm, Tinned Copper Braid Aluminium/Mylar Tape Screen, XLPE Insulation, NBR Sheath, Brown Blue Black Green/Yellow Cores, Black Sheath, -30 to 90 deg C, AS 3147, IEC 332-1
| Features |
|
|---|---|
| Brand | Aflex |
| Standard Pack Size | 1 |
| UNSPSC Class | 26121600 |
| UOM | MTR |
| Vendor Product | 777804150SC |
| Bend Radius | Static 438.75 mm/Flexible 58.5 mm |
| Conductor Size | 150 mm |
| Conductor Type | Annealed Copper |
| Core Colours | Black/Blue/Brown/Green/Yellow |
| Current | 375 Amp |
| Earth Conductor Size | 25 mm |
| Insulation Material | XLPE |
| Number of Cores | 3 Core + 3 Earth |
| Overall Diameter | 58.5 mm |
| Product Type | VSD/EMC Cable |
| Screen Material | Tinned Copper Braid Aluminium/Mylar Tape |
| Sheath Colour | Black |
| Sheath Material | Nitril Modified PVC (NBR) |
| Standards | AS 3147 IEC 332-1 |
| Temperature | -30 to 90 deg C |
| Voltage | 0.6-1 kV |
Description
Flexible: Cable, VSD EMC Screened, 3 Core & 3 Earth, 150 mm, Bare Annealed Copper, 0.6/1 kV, 375 Amp, 25 mm Earth Conductor, 58.5 mm Overall Diameter, Bend Radius: Static - 438.75 mm Flexible: 58.5 mm, Tinned Copper Braid Aluminium/Mylar Tape Screen, XLPE Insulation, NBR Sheath, Brown Blue Black Green/Yellow Cores, Black Sheath, -30 to 90 deg C, AS 3147, IEC 332-1
