Electra 0.75mm Purple Flexible Wire Heavy Duty V90HT PVC
Electra 0.75mm Purple Flexible Wire Heavy Duty V90HT PVC
In stock
SKU
ELCF1075-VTPPL
Flexible Wire, Heavy Duty, 0.75 mm, Tinned Copper, 0.6-1 kV, 7.5 Amp, 1 Core, 24/0.2 mm Strands, 2.8 mm Overall Diameter, 0.8 mm Insulation Thickness, 26.7 Ohm/km Conductor Resistance, V-90HT PVC Insulation, Purple Insulation, Unsheathed, 105 deg C, AS/NZS 1125 AS/NZS 3808 AS/NZS 5000.1 IEC 6231.1
| Brand | Electra |
|---|---|
| Standard Pack Size | 100 |
| UNSPSC Class | 26121500 |
| UOM | MTR |
| Vendor Product | F1075VT-PPL |
| Conductor Resistance | 26.7 Ohm/km |
| Conductor Size | 0.75 mm |
| Conductor Type | Tinned Copper |
| Current | 7.5 Amp |
| Insulation Colour | Purple |
| Insulation Material | V-90HT PVC |
| Insulation Thickness | 0.8 mm |
| Overall Diameter | 2.8 mm |
| Number of Cores | 1 Core |
| Sheath Material | Unsheathed |
| Standards | AS/NZS 1125 AS/NZS 3808 AS/NZS 5000.1 IEC 6231.1 |
| Stranding | 24/0.2 mm |
| Temperature | 105 deg C |
| Voltage | 0.6-1 kV |
Description
Flexible Wire, Heavy Duty, 0.75 mm, Tinned Copper, 0.6-1 kV, 7.5 Amp, 1 Core, 24/0.2 mm Strands, 2.8 mm Overall Diameter, 0.8 mm Insulation Thickness, 26.7 Ohm/km Conductor Resistance, V-90HT PVC Insulation, Purple Insulation, Unsheathed, 105 deg C, AS/NZS 1125 AS/NZS 3808 AS/NZS 5000.1 IEC 6231.1
